i-PRO WJ-NV300/12000T6 16CH NVR With 12TB Storage
Overview
The WJ-NV300/12000T6 is a 16-channel network video recorder shipped with dual 6TB hard drives (12TB total capacity) pre-installed. This configuration eliminates procurement delays on storage and delivers a ready-to-deploy NVR for mid-scale surveillance installations — retail chains, office parks, light industrial facilities — where you need to avoid separate HDD sourcing and integration work.
Compatibility
The NV300 series accepts IP cameras across i-PRO's lineup (IXE, IX, WV, and legacy Panasonic camera families) and third-party ONVIF-compliant devices. The 16-channel input supports simultaneous recording and streaming across mixed resolution streams. Integration with AXIS Camera Station, Milestone, Genetec, and other standard VMS platforms is supported via ONVIF Profile S and T.
Storage and Retention Planning
Dual 6TB drives yield 12TB usable capacity (accounting for formatting overhead, expect ~11TB practical storage). Retention duration depends on frame rate, resolution, and compression: a 16-camera mix at 1080p H.265 will record 7–10 days at 30 fps before overwriting begins. For longer retention, plan for a NAS expansion or secondary archival NVR. The drives are user-accessible; SATA interface permits field replacement without vendor intervention.
Installation Notes
Factory-configured with drives mounted and formatted; no additional HDD installation required at site. Power the unit via supplied cabling (standard dual redundant PSU option on NV300 series reduces single-point-of-failure risk). Network connection via Gigabit RJ45 ports supports both live and recorded playback streams without bandwidth bottlenecks on typical 1 Gbps infrastructure. Rack mount (1U form factor) or desktop placement; ensure adequate ventilation for the dual-drive system.
What's in the Box
- WJ-NV300 NVR chassis (16-channel)
- 2x 6TB SATA HDDs (pre-installed)
- Power cables and RJ45 network cable
- Mounting brackets and documentation
