Speco Technologies D16WHUM30TB 16-Channel Wall Mount DVR with Monitor

Overview

The D16WHUM30TB is a 16-channel hybrid DVR with an integrated 30-inch monitor mounted in a wall-mount enclosure, shipped with 30TB of internal storage. This is a turnkey surveillance install for facilities that need analog camera legacy support plus IP expansion, where a dedicated monitor rack is not feasible. The integrated display eliminates the need for a separate rack-mount monitor, reducing installation footprint and cabling complexity in SOC corners, retail back offices, and warehouse operations centers.

Compatibility

The D16WHUM30TB accepts 16 analog camera inputs (BNC connectors) and IP camera streams. It supports hybrid operation — meaning you can mix legacy analog cameras with newer IP/network cameras on the same recorder. The unit integrates with standard VMS systems that support ONVIF and Speco's proprietary management software. Storage expansion may require external SATA drives depending on Speco's design; verify drive bay configuration with documentation before purchase.

Installation Notes

Wall-mount installation requires secure structural backing to handle the combined weight of the DVR and integrated 30-inch monitor. Ensure dedicated 120V power supply; this unit does not run on backup power alone. BNC camera connections must be run from analog cameras using standard RG59 coax or hybrid cabling. IP cameras connect via standard Ethernet (PoE recommended if your switch budget allows). Position the wall mount away from direct sunlight to prevent monitor glare during evidence review. Verify room ventilation — DVRs with 30TB storage generate sustained heat under continuous recording.

What's in the Box

Exact package contents are not available in current evidence. Contact the manufacturer or reseller for a detailed box contents list before order confirmation.
