StarTech 12NM8-RACK-MOUNT-PDU 12-Outlet 1U Metered Rack Power Distribution Unit

Overview

The StarTech 12NM8-RACK-MOUNT-PDU is a 1U horizontal rack-mount PDU designed to distribute 120V AC power across 12 NEMA 5-15R outlets in a standard 19-inch equipment rack. At a rated 15A maximum total current, it covers the typical draw of a mid-density NVR stack, PoE switch, and ancillary network gear without requiring a dedicated high-amperage circuit. The steel chassis, EIA-310-D-compliant 19-inch width, and integral surge protection (UL1449 listed) make this a practical choice for small-to-midsize surveillance closets and IT rooms where reliable, organized AC distribution matters more than remote power management.

The 12NM8-RACK-MOUNT-PDU ships with an 8-foot (2.4m) NEMA 5-15P input cord — long enough to reach floor-level PDPs or wall receptacles from a mid-height rack position without an extension, which is one less point of failure to manage during an audit.

Key Features

• 12 NEMA 5-15R Outlets: Twelve individually accessible outlets along a single 1U strip give you enough ports to cover an 8-channel NVR, a managed PoE switch, a firewall, and a UPS bypass without daisy-chaining power bars — each connection point is discrete, reducing the chance of a single pull yanking adjacent gear offline.
• 15A Maximum Total Current at 120V: The 15A rating matches a standard 15A branch circuit, so you can connect this directly to a dedicated wall receptacle or UPS output without calculating derating. Size your connected load to 80% of rated capacity (12A continuous) per NEC best practice — that gives you headroom for inrush spikes when NVRs spin up HDDs simultaneously.
• Surge Protection (UL1449 Listed): The integrated surge protection carries UL1449 certification and a front-panel LED confirms the protection module is active. If a surge event clamps, the LED changes state — a quick visual check during rounds tells you whether protection has been sacrificed without pulling the unit from the rack.
• 1U EIA-310-D Compliant Form Factor: At 19.0 × 1.7 × 4.5 inches and just 4.4 lb, this unit occupies a single rack unit and satisfies EIA-310-D dimensional standards — it will fit any standard 19-inch two-post or four-post rack without adapter rails or custom hardware.
• Steel Construction: The all-steel chassis resists the flex and vibration common in active rack environments. In a cabinet shared with HVAC fans or wall-mount enclosures subject to building movement, steel holds outlet alignment better than plastic alternatives that can bow over time.
• 8-Foot Input Cord (NEMA 5-15P): The 8ft cord reaches floor PDPs or wall outlets from most rack elevations without cord management gymnastics. The NEMA 5-15P plug is the universal 15A household and commercial standard, so no adapter is needed for typical US installations.
• Operating Range 0°C to 40°C (32°F to 104°F): The rated operating temperature covers standard conditioned server rooms and most commercial IDF closets. If your rack enclosure runs warm — above 35°C ambient — confirm cooling before installing; the 40°C ceiling leaves limited margin in poorly ventilated spaces.
• 2-Year Manufacturer Warranty: StarTech backs the 12NM8-RACK-MOUNT-PDU with a 2-year manufacturer warranty, providing reasonable coverage for infrastructure hardware in a commercial deployment.

Integration & Compatibility

The 12NM8-RACK-MOUNT-PDU is agnostic to connected equipment — any device with a standard NEMA 5-15 plug drawing within the 15A aggregate budget will work. In a typical network video recorder rack, pair this PDU with a PoE switch to handle camera power separately, reserving these outlets for NVR, storage expansion, KVM, and network gear. For surveillance-specific rack builds, refer to a rack power planning guide to calculate actual load against the 15A ceiling before commissioning.

This unit provides no per-outlet switching, no remote management, and no metered per-outlet current display — it is a passive distribution and surge-protection device. If your deployment requires remote outlet control or SNMP monitoring, consider a managed PDU. For unmanaged single-circuit distributions where surge protection and outlet count are the primary requirements, the 12NM8-RACK-MOUNT-PDU handles the job without unnecessary complexity.

The EIA-310-D compliance means it drops directly into any standard 19-inch rack enclosure — open-frame two-post, four-post, or enclosed cabinet — without modification. Cable routing to the rear is straightforward given the 4.5-inch depth; most rack-mount cable management panels will clear it without interference.

Frequently Asked Questions

Q: What is the maximum load I can safely run on the 12NM8-RACK-MOUNT-PDU?

A: The unit is rated for 15A maximum total current at 120V AC. Per NEC continuous load guidelines, plan for no more than 80% of rated capacity — approximately 12A — for sustained loads. This translates to roughly 1,440W of continuous draw across all 12 outlets combined.

Q: Does the 12NM8-RACK-MOUNT-PDU support remote monitoring or per-outlet switching?

A: No. This is a passive metered PDU with a single surge protection LED indicator. It does not include SNMP management, remote outlet switching, or per-outlet current metering. If you need those capabilities, a managed PDU is the appropriate product class.

Q: What plug type does the 12NM8-RACK-MOUNT-PDU use for its input connection?

A: The unit uses a NEMA 5-15P input plug on an 8-foot (2.4m) power cord. This is the standard 15A US plug found on most NVRs, desktop switches, and IT equipment, compatible with standard NEMA 5-15R wall receptacles and UPS outputs.

Q: Will the 12NM8-RACK-MOUNT-PDU fit in any standard 19-inch rack?

A: Yes. The unit measures 19.0 inches wide and 1.7 inches tall (1U), and is compliant with EIA-310-D rack standards. It mounts in any standard 19-inch two-post or four-post rack without adapters.

Q: What certifications does the 12NM8-RACK-MOUNT-PDU carry?

A: The unit is listed to UL 60950-1 (IT equipment safety) and UL1449 (surge protective devices), and is compliant with EIA-310-D rack dimensional standards.

Q: What is the warranty on the 12NM8-RACK-MOUNT-PDU?

A: StarTech provides a 2-year manufacturer warranty on the 12NM8-RACK-MOUNT-PDU.

James Everett

The 12NM8-RACK-MOUNT-PDU is one of those infrastructure pieces that integrators overlook until they are standing in front of a partially wired rack with four devices and nowhere to plug them. The 12-outlet layout at 15A is the right spec for a single-branch-circuit surveillance rack — you get enough ports for a full NVR, PoE switch, firewall, and management gear without stacking power strips or splitting across multiple circuits, and the UL1449-listed surge protection means a transient on your building's power feed is less likely to brick your storage array on a Saturday night.

Technical Highlights:

• 15A / 120V Input Rating: Matches a standard single-pole 15A branch circuit exactly — no step-down transformer, no adapter, no derating calculation needed for a dedicated circuit. Size connected load to 12A continuous for NEC compliance.
• UL1449 Surge Protection with LED Indicator: The front-panel LED gives you passive status monitoring without logging into anything — if the protection module has sacrificed itself after a surge event, the LED tells you on your next physical walk-through, before the next event hits unprotected.
• EIA-310-D 1U Form Factor, 4.4 lb: At 19.0 × 1.7 inches and 4.4 lb, this mounts in any standard rack without rails, adapters, or weight concerns. The 4.5-inch depth keeps it clear of cable trays in most four-post cabinets.

Deployment Considerations:

• The 8-foot input cord works well for mid-rack placement reaching a floor-level UPS output, but in tall 42U cabinets with a UPS at the bottom and PDU near the top, measure before committing — you may need a longer whip or a different PDU elevation.
• This unit has no per-outlet current visibility and no network management. If your monitoring standard requires SNMP power alerts or remote reboot capability for headless NVR appliances, this passive unit is not the right fit — budget for a managed PDU instead.

For a small-to-midsize surveillance head-end rack — say, a 16-channel NVR, a 24-port PoE switch, a firewall, and a KVM on a single dedicated 15A circuit — the 12NM8-RACK-MOUNT-PDU covers the outlet count, stays within the current budget, and brings UL-listed surge protection without adding management overhead that nobody in that closet will administer anyway.
