Vertiv 11427VH - Rpdu Metered Standard 20A

Vertiv 11427VH Metered PDU

Overview

The Vertiv 11427VH is a metered, single-phase Power Distribution Unit (PDU) designed for horizontal rack mounting. It provides 16 C13 outlets with a NEMA L6-20P input plug, distributing power to IT equipment within a standard 20A circuit. This unit is ideal for data centers and network closets where precise power monitoring and reliable distribution are essential. The 11427VH allows for real-time tracking of current, power, and voltage, enabling better capacity planning and preventing overloads.

Compatibility

This PDU is compatible with standard 19-inch server racks and cabinets. Its horizontal mounting orientation is suitable for most rack enclosures. The NEMA L6-20P plug connects to a 200-240V AC input, commonly found in enterprise IT environments. The 16x C13 outlets accommodate a wide range of standard server, network, and storage devices.

Installation Notes

The Vertiv 11427VH requires a NEMA L6-20R receptacle for power input. Its 3.05-meter (10 ft) power cord offers flexibility in placement within a rack. The unit's load capacity is rated at 208 VA, with a maximum input current of 20A. It is RoHS Compliant and UL & c-UL Listed 60950, ensuring adherence to safety standards.
