Panduit 10M SM 12FB Isdt Pola ST IL Peea - FY9TP77A005M010

Panduit FY9TP77A005M010 10M Single-Mode 12-Fiber ST Trunk Cable

Overview

The Panduit FY9TP77A005M010 is a 10-meter (32.8 ft), 12-fiber single-mode pre-terminated trunk cable from the Panduit QuickNet HD Flex family — engineered for structured cabling environments where installation speed and fiber density matter. Pre-terminated at the factory with ST connectors on both ends, this trunk eliminates field termination entirely: pull it, plug it in, verify light, move on. That matters in fiber trunk cable deployments where labor time and connector quality variance are the two biggest risk factors.

The target environments are exactly what you'd expect for a pre-terminated ST trunk: data centers, telecommunications rooms, entrance facilities, and equipment distribution areas requiring pre-terminated fiber infrastructure for rapid deployment. If you're running parallel fiber runs between patch panels, HD enclosures, or distribution frames in a structured cabling buildout, this cable is designed to drop into that architecture with no field prep.

Key Features

• Pre-terminated factory construction: Both ends are factory-terminated and tested before shipment — connector geometry and insertion loss are controlled under manufacturing conditions, not job-site conditions. That removes the single biggest source of fiber link failure in new installations: inconsistent field terminations. Pull it, plug it in, done.
• ST connector interface: ST bayonet connectors on both ends suit legacy and mixed infrastructure where LC/MPO ports aren't universal. If your distribution frames or patch panels still run ST, this trunk fits without an adapter — no optical loss penalty from an in-line coupler.
• 10-meter (32.8 ft) run length: Sized for within-rack or short inter-rack runs — typical for top-of-row to end-of-row panel spans in structured telecom rooms. At 10M you're not burning excess cable that has to be managed; at the same time, you have enough slack for reasonable routing through cable trays without forced bends.
• 12-fiber count: 12 fibers in a single trunk keeps the port density high while staying manageable during installation. In a 12-fiber configuration you can support six duplex circuits per trunk — enough for a small switch uplink bundle or a structured voice/data riser segment without running multiple individual cables.
• Single-mode glass: Single-mode fiber supports longer reach and higher bandwidth than multimode — relevant when this trunk connects to equipment with single-mode transceivers (common in enterprise core switches, DWDM gear, and longer campus backbones). Matched to the correct single-mode transceiver, you get full link margin without optical budget compromise.
• QuickNet HD Flex platform: The Panduit QuickNet HD Flex line is built around high-density, pre-terminated infrastructure for fast moves, adds, and changes. HD Flex trunks are designed to work within the broader Panduit structured cabling ecosystem — enclosures, cassettes, and patch panels in the same family share form-factor compatibility for clean, maintainable installs.
• Application-ready out of the box: Designed explicitly for data centers, telecom rooms, entrance facilities, and equipment distribution areas — environments with defined cable management requirements, structured patch fields, and zero tolerance for rework. A pre-tested, pre-labeled trunk reduces commissioning time and audit trail complexity versus field-terminated links.

Integration & Compatibility

The FY9TP77A005M010 is compatible with any ST-interface patch panel, adapter plate, or bulkhead coupler in a structured cabling installation. Single-mode construction pairs with OS1 or OS2 single-mode transceivers and active equipment. Within the Panduit ecosystem, this trunk integrates with QuickNet HD enclosures and fiber patch panels designed for the HD Flex platform — consult Panduit's HD Flex enclosure lineup to confirm cassette/adapter compatibility before ordering if you're building a new rack.

For installations mixing fiber types, verify that the receiving end uses single-mode ports — connecting a single-mode trunk to a multimode transceiver will produce significant optical loss and unreliable link state. ST-to-LC or ST-to-SC coupler adapters are available if your panel interface differs, but each adapter junction adds insertion loss; design the optical budget accordingly. Consider pairing with a structured fiber patch panel or HD enclosure to complete the termination point.

Frequently Asked Questions

Q: What is the fiber type in the FY9TP77A005M010 — OS1 or OS2?

A: The FY9TP77A005M010 is single-mode (SM) construction. The specific OS1 vs. OS2 classification is not confirmed in the available product evidence — contact Panduit or consult the product datasheet to confirm the exact single-mode fiber category before specifying for long-haul applications.

Q: What connector type is on both ends of the FY9TP77A005M010?

A: Both ends are terminated with ST (bayonet) connectors. This is a ST-to-ST trunk; no adapters are needed if your patch panels or equipment use ST interfaces.

Q: How long is the FY9TP77A005M010?

A: The cable is 10 meters (32.8 feet) overall length — appropriate for short inter-rack or intra-room runs in structured cabling environments.

Q: How many fibers does the FY9TP77A005M010 contain?

A: 12 fibers, supporting up to six duplex circuits per trunk.

Q: Is the FY9TP77A005M010 compatible with multimode transceivers?

A: No. This is a single-mode cable and must be paired with single-mode transceivers. Connecting it to multimode equipment will result in severe optical loss and unreliable or failed links.

Q: What applications is the FY9TP77A005M010 designed for?

A: Data centers, telecommunications rooms, entrance facilities, and equipment distribution areas requiring pre-terminated fiber infrastructure for rapid deployment — per Panduit's stated application guidance for this product.

Jerry Tildsen

The FY9TP77A005M010 is a straightforward workhorse for structured cabling buildouts where you need single-mode 12-fiber capacity at a 10-meter run length, factory-terminated with ST connectors and ready to deploy without any field splicing or polishing. The key spec to lock in before ordering is the connector type: ST bayonet on both ends means this trunk fits cleanly into legacy ST-interface panels without adapters, avoiding the optical budget penalty you'd pay at each coupler junction if you had to adapt to a different interface.

Technical Highlights:

• 12-Fiber, Single-Mode: 12 SM fibers in one trunk support six duplex circuits — enough to cover a full switch uplink bundle in a single pull, eliminating the labor and cable management complexity of six individual duplex runs.
• 10M / 32.8 ft pre-terminated run: Factory termination at exactly 10 meters removes field connector quality variance, the most common source of insertion loss deviation in new installations; the trunk arrives tested and labeled.
• ST interface: ST connectors are the exact right choice when your distribution frames or patch panels use ST ports — no in-line adapter means no added 0.2–0.5 dB loss per junction, which matters when you're stacking multiple links in a lossy structured cabling path.

Deployment Considerations:

• Confirm single-mode transceiver compatibility at both ends before pulling this trunk — pairing SM glass with MM transceivers is a hard failure, not a graceful degradation. Audit your active equipment's SFP/SFP+ part numbers before ordering.
• ST connectors require a quarter-turn bayonet engagement and are more susceptible to accidental disconnection in high-vibration or high-touch environments than LC or SC latch interfaces — factor this into your patch panel selection if the telecom room sees heavy MACs.

This trunk is a natural fit for enterprise telecom room structured cabling refresh projects where existing patch panels are ST-based and the goal is accelerating installation time by eliminating field termination entirely — particularly in entrance facilities or equipment distribution areas where a 10M span between frames is the standard run distance.
