Altronix 10BASE-T1L/ET MD 24V PW SP KIT - PACE1KRL24S

Altronix PACE1KRL24S Concise Descriptor

Overview

The Altronix PACE1KRL24S is a specialized kit designed to extend Ethernet connectivity using the 10BASE-T1L standard. This allows for data transmission and 24VDC power delivery over a single twisted pair cable, significantly increasing deployment flexibility for IP devices. It's engineered for scenarios where running traditional Cat5e/Cat6 cable is impractical or cost-prohibitive, such as long-distance runs or retrofitting older infrastructure. The PACE1KRL24S kit includes both the transmitter and receiver units, making it a complete solution for enabling IP devices at extended distances.

Compatibility

This kit is specifically designed to work with Altronix's PACE 10BASE-T1L product line. It enables the transmission of data and 24VDC power to compatible IP cameras, access control devices, or other network endpoints that support 10BASE-T1L. The system is intended for use with devices requiring up to 24VDC input and standard Ethernet data rates over the extended range. Consult Altronix documentation for a definitive list of compatible endpoint devices and specific range limitations based on cable type and power draw.

Installation Notes

Installation requires terminating a single twisted pair cable between the transmitter and receiver units. Ensure the cable is rated appropriately for the distance and environmental conditions. The kit delivers 24VDC power, so ensure connected devices are compatible with this voltage. Maximum transmission distance is dependent on cable quality, environmental factors, and the power consumption of the connected device. Verify signal integrity and power delivery before commissioning the endpoint device.

What's in the Box

• 1x PACE1KRL24S Transmitter Unit
• 1x PACE1KRL24S Receiver Unit
