Comnet FVR110M1 10-Bit Video Receiver with Extended Fiber Distance

Overview

The Comnet FVR110M1 is the receiver half of a paired video transceiver system that carries short-haul EIA RS-250C digitally encoded video and bi-directional control data over optical fiber — solving the distance and noise immunity problem when analog video coaxial runs become impractical. Deploy this unit at the far end of a fiber link to recover video and data from a transmitter (FVT110) mounted near your camera or PTZ head. The FVR110M1 handles 10-bit video encoding standard in broadcast-grade surveillance systems, supporting simultaneous bidirectional RS232, RS422, or RS485 data at rates up to 250 kbps.

Compatibility

Compatible with Panasonic Proteus, Pelco Coaxitron, and Bosch Bilinx up-the-coax control systems. The receiver accepts both multimode (MM) and single-mode (SM) fiber variants — specify the matching transmitter (FVT110M1 for multimode, FVT110S1 for single-mode) to complete the pair. Works with any EIA RS-250C camera or PTZ that outputs standard composite video and supports one of the three data protocols (RS232, RS422, 2/4-wire RS485) or contact closure signaling.

Installation Notes

Operating voltage 8–15 VDC, power draw 5.25W — size your power supply accordingly. The FVR110M1 ships in ComNet ComFit packaging, compatible with wall, rack, or DIN-rail mounting (DIN rail requires optional DINBKT1 adaptor). Temperature range -40°C to +75°C operating, -40°C to +85°C storage, 0–95% non-condensing humidity. Optical power budget 16 dB supports up to 3 km multimode or 48 km single-mode distance — verify your fiber run length and loss budget before deployment. MTBF >100,000 hours. LED status indicators (bi-color red/green) flag critical operating parameters; automatic resettable fuses protect all power lines; voltage transient protection on all power and signal I/O.
