The Hanwha PNM-C34404RQPZ/KEX is a ruggedized 2MP outdoor PTZ camera engineered for high-impact security environments requiring durability, low-light performance, and flexible coverage.
Image quality is delivered through 2MP resolution paired with varifocal lens capability and advanced WDR (Wide Dynamic Range) processing. The camera achieves exceptional low-light sensitivity at 0.1 Lux in color mode (F1.5, 1/30sec) and 0.05 Lux (F1.6, 1/30sec), complemented by IR illumination for complete 24/7 visibility. H.265, H.264, and MJPEG codec support ensures flexible compression and compatibility with diverse NVR and VMS platforms. Up to 85 characters of on-screen display text support aids in scene identification and audit trails.
Built for extreme environments, this camera carries IP66 rating for dust and water ingress protection and IK10 classification against impact and vandalism—essential for exposed outdoor installations, transit hubs, and perimeter security. The metal-shielded RJ-45 Gigabit Ethernet connection (10/100/1000BASE-T) resists electromagnetic interference. Operating temperature range of −50°C to +60°C accommodates harsh climates from arctic to desert installations. NEMA 250 Type 4X enclosure rating confirms weather and corrosion resistance.
PoE++ (802.3bt Type 4, Class 8) powered deployment eliminates separate power runs and simplifies installation in remote or difficult-to-wire locations. The camera ships with either 8GB RAM/1GB Flash or 4GB RAM/512MB Flash configurations to support on-device analytics and video buffering. Secure boot, signed firmware, and firmware encryption protect against unauthorized access and tampering.
Integration is straightforward via ONVIF compliance and Hanwha's SUNAPI HTTP API, enabling control through third-party VMS platforms, custom applications, and IP security ecosystems. Network disconnect detection, alarm input capability (via optional SPM-4210 I/O box), app-based events, and scheduling features provide flexible alerting and automation workflows.
Key Features:
- 2MP resolution with varifocal lens and WDR for dynamic scene clarity
- 0.1 Lux color + IR night vision for around-the-clock surveillance
- IP66/IK10 rated—vandal-resistant, weather-sealed construction
- PoE++ powered for simplified deployment in remote areas
- H.265/H.264/MJPEG codec flexibility and ONVIF compatibility
- Secure firmware architecture with boot protection and encryption
The PNM-C34404RQPZ/KEX is purpose-built for punishing outdoor environments where standard cameras fail—perimeter fences, parking structures, transit platforms, and utility corridors. The IK10 vandal rating combined with IP66 sealing means you're not replacing this unit after the first impact or rainstorm. PoE++ support is a major deployment advantage in remote sites lacking dedicated power infrastructure. The low-light performance (0.1 Lux color) is production-grade, and H.265 codec efficiency keeps bandwidth and storage lean without sacrificing image detail. Consider this unit when durability and 24/7 reliability outweigh megapixel count.
