Vertiv 13365 20A Vertical Basic Surge Rackmount PDU
Overview
The Vertiv PowerIT rPDU 13365 (model VSSBN204-102R20) is a 66-inch vertical rackmount power distribution unit built for IT racks and cabinets that need reliable 20A/120V power delivery with built-in surge suppression. If your facility lacks upstream surge protection — or if you're adding a second layer of protection at the rack level — this PDU addresses that gap directly with 720 joules of surge capacity and Super MOV technology, all in a compact 1.61-inch square profile that fits standard zero-U vertical mounting positions without consuming rack unit space.
Every unit ships 100% tested from the factory and carries a standard five-year limited warranty, including a $5,000 connected equipment warranty — meaningful coverage if you're distributing power to active network gear, storage, or surveillance recording equipment.
Key Features
- 20x NEMA 5-20R Outlets at 2.8-Inch Spacing: Twenty individually rotated 5-20R receptacles spread across the 66.25-inch chassis give you density without cable congestion. At 2.8 inches center-to-center, most standard power supplies and IEC adapters clear each other cleanly — fewer conflicts than tighter-pitch alternatives when you're wiring a full rack.
- 720-Joule Surge Protection, 340V Clamping Voltage: The 720J rating handles routine transients from HVAC cycling, generator transfers, and utility fluctuations. The 340V maximum clamping voltage means surge energy is diverted before it reaches equipment — compare this against the 400V+ clamping on budget strips and the difference matters for sensitive switching power supplies.
- Super MOV Surge Technology with Red LED Indicator: Metal Oxide Varistors provide fast-response clamping; a dedicated red LED lights if the surge protection stage is degraded or sacrificed, so you know at a glance whether the unit still provides protection — no guessing, no silent failure.
- 20A Thermal Breaker Over-Current Protection: The built-in thermal circuit breaker trips on sustained overload and resets without tools — useful in live rack environments where replacing a fuse at 2 AM is not an option. At 1.9kW (120V) load capacity, this handles a fully populated rack of 1U switches or NVRs without reaching the breaker threshold under normal operating conditions.
- 10-Foot 12/3 AWG Power Cord with NEMA 5-20P Plug: The 10-foot cord reaches most in-row PDU panels or wall circuits without extension cords. 12-gauge wire is the correct gauge for a 20A circuit — undersized wiring on 20A feeds is a real problem with cheaper alternatives and this spec eliminates that concern.
- TAA Compliant and Buy American Act COTS Compliant: Country of origin is USA. For federal deployments, GSA purchases, or any contract requiring TAA or BAA compliance, this unit qualifies — a spec that immediately disqualifies many competing surge PDUs imported from non-TAA countries.
- Vertical Zero-U Mounting, 66.25-Inch Profile: The chassis mounts in the vertical channel of a standard open-frame or enclosed rack using the included plastic mounting clips (1 bottom, 2 top), preserving every rack unit for active equipment. At 66.25 inches it fits standard 42U rack depths without overhang.
- Green Power-On LED Indicator: A single green LED confirms the unit is energized. Simple, but useful for quick visual confirmation during rack commissioning or after a power event — you see status without pulling a meter.
- Operating Range 10–45°C (50–113°F): Covers standard data center, IDF closet, and rack enclosure thermal ranges. Not rated for outdoor or uncontrolled environments — deploy in conditioned or semi-conditioned spaces.
- RoHS and UL/c-UL Listed 60950: UL listing to the 60950 standard covers IT equipment power distribution specifically. RoHS compliance matters for e-waste and import regulations in EU and some US state programs.
Integration and Compatibility
The VSSBN204-102R20 is a rackmount power distribution unit in Vertiv's Vertiv PowerIT rPDU line, the Basic Surge sub-category. It does not include metering, monitoring, or switched-outlet capabilities — those require stepping up to Vertiv's Monitored or Switched rPDU families. For NVR and surveillance recorder racks where you need power visibility per outlet or remote outlet control, evaluate the Vertiv metered or switched variants instead.
The NEMA 5-20R receptacles accept 5-20P and 5-15P plugs — the standard footprint for 1U/2U servers, PoE network switches, and most rackmount surveillance equipment. No adapters needed for typical IT and security rack loads. For racks already fed by a UPS with surge suppression built into the output stage, adding a second surge PDU is a judgment call — the 720J here supplements rather than replaces a quality UPS bypass stage.
Chassis color is black powder coat as standard. Custom color options are available through Vertiv's sales channel if rack color-coding is a requirement for your deployment.
Frequently Asked Questions
Q: Is the Vertiv 13365 TAA compliant for federal or government purchases?
A: Yes. The 13365 (VSSBN204-102R20) is manufactured in the USA and is documented as TAA Compliant and Buy American Act COTS Compliant per the product specification sheet.
Q: What is the surge joule rating and clamping voltage on the 13365?
A: The 13365 provides 720 joules of surge absorption capacity with a maximum clamping voltage of 340V, using Super MOV technology. A red LED indicator alerts you if the surge protection stage has been compromised.
Q: How many outlets does the VSSBN204-102R20 provide, and what receptacle type?
A: Twenty NEMA 5-20R receptacles, individually rotated, spaced 2.8 inches center-to-center along the 66.25-inch vertical chassis. Each outlet supports up to 20A at 120V.
Q: What is the warranty on the Vertiv 13365?
A: Vertiv provides a 5-year limited warranty on the unit itself, plus a connected equipment warranty of $5,000 for five years covering equipment damaged due to a surge event while connected to the PDU.
Q: Does the 13365 include metering or outlet switching?
A: No. The VSSBN204-102R20 is a Basic Surge rPDU — it provides power distribution and surge protection only, with no per-outlet metering, remote monitoring, or switched outlet control. If you need those capabilities, consider Vertiv's Monitored or Switched rPDU families.
Q: What plug type does the 13365 use, and how long is the power cord?
A: The 13365 ships with a 10-foot 12/3 AWG cord terminated in a NEMA 5-20P plug, compatible with standard 20A commercial circuits. The 12-gauge wire is correctly rated for the 20A circuit capacity.
The detail I keep coming back to on the 13365 is the connected equipment warranty — $5,000 for five years is a real backstop, not a marketing footnote, and it's only meaningful if the clamping voltage is tight enough to do the job. At 340V maximum clamping, the VSSBN204-102R20 is doing what it should: diverting transient energy before it reaches the load. A lot of budget surge strips claim similar joule ratings but clamp at 400V or higher, which is where the damage actually starts for switching supplies running at 85–90% efficiency targets.
Technical Highlights:
- 720J / 340V Clamping: The Super MOV stage absorbs cumulative transient energy up to 720 joules and clamps at 340V — tighter than many competitors in this price range, which translates to better protection for sensitive rectifier stages in NVRs and managed switches.
- 20A Thermal Breaker: Trips on sustained overload and resets without tools — critical in live environments. At 1.9kW load capacity on a 120V/20A circuit, you have real headroom before the breaker sees stress under typical surveillance or IDF rack loads.
- TAA / BAA Compliance, USA Origin: Government, education, and healthcare deployments with TAA requirements can specify this unit directly — no country-of-origin exception paperwork required.
Deployment Considerations:
- The 66.25-inch chassis fills a standard 42U rack vertical channel precisely — confirm your cabinet's vertical mounting rail depth and clip-slot positions before ordering if you're using non-standard enclosures.
- This is a passive surge PDU: no Ethernet port, no SNMP, no outlet-level current data. If the rack is part of a monitored power infrastructure (DCIM, BMS, or remote NOC), you'll need to step up to a metered or managed Vertiv rPDU to get visibility. The 13365 is the right tool only where local visual confirmation (the green and red LEDs) is sufficient.
For a surveillance IDF closet or small security equipment rack running NVRs, PoE switches, and access control panels on a 20A dedicated circuit — without DCIM requirements — the 13365 is the correct specification. Its TAA lineage and connected equipment warranty also make it a defensible choice for K-12 and municipal security deployments where procurement compliance is scrutinized.
