Vertiv CPQ-1050164-01 Concise Descriptor

Overview

The Vertiv CPQ-1050164-01 is a 20A, 120V rackmount power distribution unit (PDU) designed to provide reliable power to IT equipment within a standard server rack. It features 6 L5-20R outlets, offering sufficient capacity for a small to medium density rack configuration. This unit is critical for maintaining operational uptime by ensuring consistent power delivery to servers, switches, and other essential network hardware. Its 33LN-6LO-W designation indicates a specific configuration for North American power grids and outlet types.

Compatibility

This PDU is designed for use with standard 19-inch server racks and cabinets. It is compatible with equipment requiring L5-20R power connectors and operates within a 120V, 20A electrical service. It integrates seamlessly into existing rack infrastructure where standard power distribution is required, supporting a wide range of IT hardware from various manufacturers that adhere to these power specifications.

Installation Notes

Installation requires a standard NEMA L5-20P input plug to connect to a 120V, 20A circuit. Ensure the circuit breaker feeding the PDU is rated for 20A to prevent nuisance tripping. The unit should be mounted vertically within the rack, utilizing the provided mounting brackets. Proper airflow must be maintained around the PDU and connected equipment to prevent overheating. Verify that the total power draw of connected devices does not exceed the PDU's 20A capacity.

What's in the Box

• 1x Vertiv CPQ-1050164-01 PDU
• 1x Power Cord (NEMA L5-20P to L5-20R)
• Mounting Brackets
