Sensor Type:
1/2.7" Progressive CMOS
Resolution:
HD 4864 x 1632 (8MP), SD 2432 x 816
Lens Type:
Fixed focal
Focal Length:
f= 2.8 mm
Aperture:
F1.2
Iris:
Fixed iris
Field of View:
180° (Horizontal)/ 50° (Vertical)/ 180° (Diagonal)
Camera Movement:
Tilt: 20°
Shutter Speed:
1/30 sec. to 1/32,000 sec.
Day/Night:
Yes
IR Cut Filter:
Yes
IR Distance:
20 meters
Minimum Illumination:
0.018 Lux (Color),
Onboard Storage:
512GB microSD card slot
Frame Rate:
15FPS
Video Streaming Settings:
HD 8MP@15fps 3Mbps, SD@15fps 400Kbps
Audio Support:
One way Audio
Effective Range:
5 meters
Audio detection:
Yes
Tampering detection:
Yes
People Analytics:
Intrusion detection, Line crossing detection, Loitering detection, Appearance Search, Scene Search, Re Search
Vehicle Analytics:
Intrusion, Line crossing, Loitering detection
Object Analytics:
Unattended object detection, Missing object detection
Input Voltage:
IEEE 802.3at PoE Class 4
Power (Max:
Max: 20W / 13.5W (IR on/ IR off)
Connectivity:
RJ 45 cable connector for 10/100 Mbps PoE network connection
RTSP:
RTSP/RTP/RTCP, WebRTC
Users:
6 concurrent users
Security:
Secure boot, Signed firmware, HTTPS/TLS encryption, Video encryption
Interface:
10 Base T/100 Base TX Ethernet (RJ 45)
Operating Temperature:
40°C to 50°C (IR on); 30°C to 55°C (IR off)
Humidity:
90% RH (non condensing)
Features:
EMC: CE (EN 55032, EN 55024 Class A), FCC (FCC Part 15 Subpart B Class A), RCM (AS/NZS CISPR 32 Class A), VCCI (VCCI CISPR 32 Class A); UKCA (BS EN 55032: 2015 +Q71: 2020, BS EN 55035: 2017 +Q71: 2020); Safety: UL (UL 62368 1), CB (IEC/EN 62368 1
Warranty:
60 month
Included Accessories:
Quick installation guide, alignment sticker, desiccant bag, screw driver, screws pack, sunshield
Weight:
1.2kg
Dimensions:
165 x 112 x 97 mm (w/o sunshield), 165 x 100 x 119 mm (w/ sunshield)
Body:
Metal
Type:
Box
Product Type:
Box
Power Type:
PoE
Night Vision:
IR
Housing Color:
White
