TSC SP-TC200-0048 Main Board with RTC

TSC SP-TC200-0048 Main Board with RTC Module

Overview

The TSC SP-TC200-0048 is a replacement main board and real-time clock (RTC) module designed for TC310 thermal printer systems. This component is supplied as a complete set per box and serves as a critical control and timing element in inkjet-based label and tag printing workflows. The 600 dpi resolution capability enables precise, high-fidelity label output for industrial identification, logistics, healthcare, and retail applications.

Key Features

• 600 DPI Print Resolution: Delivers sharp text, barcodes, and graphics for demanding labeling requirements
• Main Board + RTC Integration: Combines primary processor control with integrated real-time clock for accurate timestamp and scheduling functions
• Inkjet Print Method: Supports ink-based printing technology compatible with TC310 printer architecture
• Wired Connectivity: Integrates with standard network and direct-connection interfaces for reliable printer communication
• TC310 Compatible: Engineered specifically for TC310 thermal printer models and system configurations
• Complete Set: Arrives as a fully assembled, ready-to-install module — one set per box

Technical Specifications

The SP-TC200-0048 operates at 600 dpi resolution, supporting high-fidelity inkjet output across supported media widths. The integrated RTC ensures accurate time-stamping and synchronized printing operations critical to batch processing and sequential labeling tasks. Wired connectivity provides direct communication pathways for system integration in manufacturing, warehouse, and distribution environments where network reliability and latency control are priorities.

Installation and Compatibility

This replacement board is designed for direct integration into TC310 printer systems. Technical integrators and field technicians should reference TSC's system documentation for installation procedures, connector mapping, and firmware compatibility verification before deployment. The component is supplied as a complete, tested unit ready for installation.

Package Contents

One (1) complete SP-TC200-0048 main board and RTC module set per box. The component arrives assembled and ready for installation into compatible TC310 printer systems.

Ted Perry

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

During equipment refresh cycles and field repairs, the TSC SP-TC200-0048 main board becomes essential for restoring TC310 printer functionality. This component combines processing control with real-time clock functionality, ensuring both operational stability and accurate timestamp integration across your printing workflow. When you're managing printer uptime in high-volume environments, having the correct replacement board on hand minimizes downtime.

Technical Highlights:

• 600 DPI Output: Maintains label quality and barcode readability critical to downstream scanning and tracking operations
• RTC Accuracy: Integrated real-time clock ensures synchronized printing and prevents timestamp drift across networked printer deployments
• Inkjet Integration: Supports ink-based printing workflows for applications requiring variable data or color capability within TC310 systems

Deployment Considerations:

• Verify firmware version compatibility before installation to avoid system boot or communication errors
• Ensure power cycling and proper connector seating during installation to establish stable operation
• Test RTC synchronization immediately after installation to confirm timestamp accuracy in batch operations

The SP-TC200-0048 is a straightforward replacement solution for system restarts and preventive maintenance cycles. Keep technical documentation and connector diagrams accessible during installation to ensure clean integration and immediate operational validation.
