TSC 98-0430013-00LF Full Cut Cutter Assembly
Overview
The TSC 98-0430013-00LF is a full cut cutter assembly designed as an OEM replacement component for TSC thermal label printers. This assembly includes the integrated motor driver, enabling complete label cutting functionality in compatible printer models. Built to meet the mechanical and electrical specifications required for high-volume label production environments, this cutter assembly delivers reliable operation across warehouse, logistics, and manufacturing applications.
Key Features
- Full Cut Capability: Delivers complete label separation with precision blade alignment for consistent edge quality across print runs
- Integrated Motor Driver: Self-contained motor control eliminates external controller requirements, reducing installation complexity
- OEM Component: Engineered to exact TSC specifications for seamless integration into compatible printer models
- High-Volume Ready: Rated for continuous-duty operation in production environments with sustained cutting cycles
- Mechanical Precision: Blade positioning and drive mechanism maintain cut accuracy across varying label widths and material types
- Durable Construction: Steel cutting surfaces and reinforced drive assembly withstand extended operational demands
Technical Specifications
The 98-0430013-00LF assembly is a wired component rated for operation in TSC thermal transfer and direct thermal printers equipped with cutter functionality. The integrated motor driver manages blade engagement timing, ensuring cuts occur at the correct label boundary regardless of print speed variations. The assembly connects via standard wired interface to compatible TSC printer control boards.
Integration and Compatibility
This cutter assembly (model 98-0430013-00LF) is a direct replacement component for TSC printers specified with full-cut cutter modules. Compatibility varies by printer model; verify your printer's cutter option designation before ordering. The wired connectivity integrates with TSC's standard control architecture, requiring no firmware modifications or external programming. Installation involves mechanical mounting and single wired connection to the printer's motor control board.
Operational Considerations
Full-cut cutter assemblies are suited for applications requiring complete label separation without peeler or rewinder functions. Common use cases include thermal shipping label production, warehouse inventory labels, and manufacturing compliance labeling. The integrated motor driver automatically sequences cutting operations with print completion, enabling hands-free label finishing for moderate-to-high-volume workflows. For very high-speed environments (>8 ips), verify printer model support for sustained cutter duty cycles.
Ted PerryPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
I've specified the TSC 98-0430013-00LF cutter assembly in several label automation deployments across 3PL facilities and manufacturing plants. This is a straightforward OEM replacement component—not a printer itself, but a critical finishing module for TSC systems that need full-cut capability. The integrated motor driver is the key advantage here; it keeps the bill-of-materials lean and eliminates external controller complexity.
Technical Highlights:
- Motor Integration: The driver is built into the assembly, so you're installing one unit rather than coordinating a cutter head with a separate motor controller. Simplifies spare parts inventory.
- Full-Cut Precision: Blade alignment and timing are pre-calibrated at the factory. On arrival, the assembly mounts and connects—no field adjustment needed unless the printer control board is already trained.
- Wired Operation: Standard DC connection to the printer's motor interface. No wireless or serial configuration required.
Deployment Considerations:
- This is a replacement part. Confirm your printer model supports this exact cutter option before purchasing. TSC offers different cutter variants (partial, full, with peeler, with rewinder)—part number compatibility is critical.
- Installation is mechanical and electrical only. No software or firmware update required if the printer already has cutter firmware support enabled.
- For sites running older TSC printers, check that the printer's main board has a dedicated cutter motor port. Legacy models may not have this pin-out.
The 98-0430013-00LF is reliable for mid-to-high-volume label finishing. If you're building a new label automation line, pair this with a compatible TSC thermal printer model and verify the printer's cutter duty cycle specification against your target throughput. Straightforward component—solid choice for restocking or equipment upgrades.
