TSC 98-0390020-10LF TDP-225W Media Sensor Assembly

TSC 98-0390020-10LF TDP-225W Media Sensor Assembly

Overview

The TSC 98-0390020-10LF is a media sensor assembly for the TDP-225W direct thermal printer. This component detects and positions media (labels, wristbands) during print cycles, ensuring consistent feed alignment and output quality. At 203 dpi resolution, it supports high-volume warehouse, logistics, and inventory labeling operations where accurate media advancement directly impacts label readability and barcode scan rates.

Compatibility

Designed exclusively for TSC TDP-225W direct thermal systems. Compatible with label and wristband media formats up to 52 mm (2.05") print width and 2,286 mm (90") maximum length. Integrates with the TDP-225W's 32-bit RISC processor and USB 2.0 interface — no additional software drivers beyond the included Windows labeling software CD.

Installation Notes

Media sensor assembly operates within 5–40°C ambient temperature and 25–85% non-condensing humidity — standard for climate-controlled warehouse environments. Power draw is 50W (DC 24V, 2.08A) via the external universal switching power supply included with TDP-225W systems. Mount on the printer's clamshell frame using the existing fastener points; no additional tools or torque specifications are required beyond standard assembly practices. USB connection ensures stable, interference-free sensor communication without wireless signal loss.

What's in the Box

• 1x TDP-225W media sensor assembly
• 1x external universal switching power supply (AC 100–240V input, DC 24V, 2.08A output)
• Windows labeling software CD disk
