Vertiv WLPTOB Tilt-out Bracket SET 4 RU

Overview

The Vertiv WLPTOB is a 4U rack-mount tilt-out bracket set designed to provide rear access for network and security equipment installed in standard 19-inch racks. This bracket system allows you to swing out mounted devices for easier maintenance, cable management, and component replacement without fully removing the equipment from the rack. It is specifically engineered for environments where frequent access to the rear of installed devices is necessary, such as server rooms, network closets, and security monitoring stations.

Compatibility

This tilt-out bracket set is designed for use with standard 19-inch rack enclosures. It provides 4U (approximately 7 inches) of vertical mounting space. While not specific to a single product line, it is intended for mounting standard rack-mountable equipment like network switches, NVRs, servers, or patch panels that require rear access. Confirm your existing rack's depth and mounting hole compatibility before installation.

Installation Notes

Installation requires mounting the bracket set to the front vertical rails of a 19-inch rack using standard rack screws (not included). The tilt-out mechanism allows for approximately 90 degrees of swing, providing access to the rear of the mounted equipment. Ensure sufficient clearance is available behind the rack for the tilt-out operation. The bracket set is designed to support the weight of typical rack-mount equipment within its 4U capacity.
