Altronix T3M77XK1D/WITH LINQ - T3M77XK1DQ

Altronix T3M77XK1DQ Concise Descriptor

Overview

The Altronix T3M77XK1DQ is a multi-purpose timer board designed for 6/12VDC systems, providing precise timing control from 1 second up to 60 minutes. This board is critical for synchronizing operations in access control and surveillance deployments, ensuring sequential activation or deactivation of devices based on programmed delays. Its compact form factor allows integration into various system enclosures where precise timing is a requirement.

Compatibility

This timer board is engineered to integrate with Altronix access control power controllers such as the ACM4, ACM4CB, ACM4CBE, ACM8, ACM8CB, ACM8CBE, ACMS12, ACMS12CB, ACMS8, ACMS8CB, ACMS8CBK1, and ACMS8K1 series. It is also compatible with Altronix power supplies like the AL1002ADA220, AL1002ULADA, AL1002ULADAJ, AL100UL, AL1012ACM220, and AL1012ACMCB220. The T3M77XK1DQ is suitable for systems requiring timed relay closures or openings within the specified voltage and time ranges.

Installation Notes

The T3M77XK1DQ operates on 6VDC or 12VDC input. Ensure the power source is within these parameters to prevent damage. The board provides adjustable timing from 1 second to 60 minutes, configurable via onboard jumpers or switches as per the system requirements. Proper wiring to the control inputs and output relays is essential for correct operation. Refer to the specific Altronix enclosure or system manual for detailed wiring diagrams and mounting instructions.

What's in the Box

• 1x T3M77XK1DQ Timer Board
