APC by Schneider Electric SUA500PDR-H Concise Descriptor
Overview
The APC by Schneider Electric SUA500PDR-H is a line-interactive Uninterruptible Power Supply (UPS) designed for critical equipment protection in environments where space is constrained and reliable power is paramount. This unit provides 500VA/325W of power capacity and features a DIN rail mountable form factor, making it suitable for integration into industrial control panels, network closets, and surveillance system racks. It ensures continuous operation during power fluctuations and brief outages, safeguarding sensitive electronics from data corruption and hardware damage. The SUA500PDR-H offers 540 Joules of surge energy dissipation, protecting connected devices from damaging voltage spikes.
Compatibility
This UPS is designed for direct hardwire connection, suitable for systems requiring a 120V AC input and output. Its primary application is to provide backup power for sensitive electronics within industrial automation, network infrastructure, or security systems that utilize DIN rail mounting for components. It is compatible with equipment requiring a stable 57-63 Hz output frequency and can accept input voltages ranging from AC 82-144V, with an adjustable range of AC 75-154V, offering flexibility in various power conditions.
Installation Notes
The SUA500PDR-H requires a hardwire 3-wire (1PH + N + G) input connection and provides a hardwire 3-wire (HN + E) output connection. It operates within a temperature range of 32°F to 122°F (0°C to 50°C) and 0-95% non-condensing humidity. The unit has a sound emission level of 55 dBA. It features a SmartSlot for optional network management cards and an RS-232 interface for serial communication and monitoring. An EPO (Emergency Power Off) port is included for immediate shutdown in critical situations.
What's in the Box
- 1x APC SUA500PDR-H UPS
- 1x RS-232 communication cable
- 1x EPO connector
- 1x Mounting bracket for DIN rail
