Middle Atlantic STL Ext. Elbow 700 White - 718WH

Middle Atlantic 718WH Steel 700 Series Outside Elbow Fitting — White

Overview

The Middle Atlantic 718WH is a steel outside elbow fitting designed for use with the Middle Atlantic 700 Series raceway and cord cover system. Outside elbows handle direction changes at protruding corners — walls meeting at outside angles — keeping cable runs continuous and concealed without exposed wiring or improvised bends. The 718WH finishes in white to match standard commercial wall paint and ceiling tile environments. TAA-compliant construction makes it a straightforward fit for government and federally funded installations where country-of-origin requirements apply to every component in the pathway, including fittings.

Compatibility

The 718WH is purpose-built for the Middle Atlantic 700 Series raceway system. It mates with 700 Series base and cover profiles to form clean outside corners along cable pathways. For inside corners, the corresponding inside elbow fitting in the same series applies. If your run requires a flat transition or end cap, those are separate 700 Series fittings — the 718WH is specific to outside-angle direction changes only. Verify your existing raceway series before ordering: the 700 Series profile dimensions are not interchangeable with Middle Atlantic's other raceway families.

Installation Notes

Mount the 718WH at the outside corner junction before routing cable through the channel — attempting to fish cable around a corner post-assembly increases the risk of insulation damage on sharp steel edges. Secure the fitting to the raceway base using the same fastener pattern as the standard 700 Series covers. No specialty tools are required beyond standard installation hardware used with the broader 700 Series fitting set.
