STI KIT-M05050-B Translucent Blue Lens Lock/Strike
Overview
The KIT-M05050-B is a 9VDC translucent blue lens lock/strike assembly designed for credential-based access control at single or multi-door installations. The translucent blue lens provides visual feedback during strike activation — useful in high-traffic entry points where operators and integrators need immediate confirmation that the strike has energized. This is a physical strike component, not a control panel or reader; it installs downstream of your access control logic to execute door unlock commands.
Compatibility
Integrates with any access control system architecture that outputs a 9VDC strike control signal — typically from a door controller, panel relay output, or networked access management system. Compatible with standard fail-safe and fail-secure strike configurations depending on your wiring and control logic. Verify your control panel's strike output voltage and relay capacity (must support the strike's inrush and holding current) before installation. The translucent lens housing is color-coded blue to support visual wayfinding or access-level differentiation in multi-door environments.
Installation Notes
Mount the strike assembly to the door frame using the provided fixing points. Ensure the strike aligns with the door latch bolt to avoid binding during unlock cycles. Wire the 9VDC power and control signal directly to the panel's strike relay output — use appropriately sized wire and observe polarity. Protect outdoor installations or high-moisture areas with weatherproofing conduit; the translucent polycarbonate lens is tough but not inherently sealed against standing water or salt spray. Test the unlock/lock cycle under load before commissioning to confirm smooth operation and proper solenoid engagement.
What's in the Box
- 1x KIT-M05050-B translucent blue lens strike assembly
- 1x 9VDC solenoid module
- Mounting hardware (frame and fasteners)
