STI KIT-EA135 Deactivation Pin HID Credential Lock
Overview
The KIT-EA135 is an electromechanical strike assembly designed for HID credential-based access control installations. Operating at 9VDC, this deactivation pin mechanism functions as a controlled strike suitable for single and multi-door commercial deployments. The strike activates only when a valid HID credential is presented to the integrated reader, eliminating the need for manual unlock buttons or bypass logic at the door. Install this where door access must be tied directly to credential verification — retail entry points, server rooms, secure storage areas, or any environment where unauthorized access represents a physical or data security risk.
Compatibility
The KIT-EA135 integrates with HID credential systems that output strike-control voltage. Compatible with HID reader platforms and access control panels that support 9VDC electromechanical strike activation. Wiring connects to standard access control panel relay outputs or dedicated strike control modules. Confirm your existing panel or reader outputs a 9VDC strike signal before ordering. Retrofit and new construction installations both support this assembly where door hardware can accommodate a deactivation pin strike mechanism.
Installation Notes
Requires a dedicated 9VDC power supply capable of sustaining the draw during strike activation — verify your panel's strike output capacity before installation. Mount the strike assembly into or adjacent to the door frame, following OEM mounting templates. Wire the 9VDC common and signal lines to the access control panel's strike relay output. Test credential presentation and strike activation before final commissioning. No special tools beyond standard electrical hand tools and a torque wrench (if torque specifications are provided in the strike documentation) are required.
