Panduit FRTSC12W6LBL Split Cover Horizontal Tee with 6-Inch Exit

Overview

The FRTSC12W6LBL is a split cover horizontal tee fitting designed for Panduit's Opti-Core® fiber raceway systems. This component provides a managed 90-degree branch point in a horizontal cable pathway, with an integrated 6-inch exit section — purpose-built for installations where fiber runs need to split off to secondary distribution points without disturbing existing cable bundles. The split cover design allows installers to add or re-route fiber after initial installation without pulling cables through a sealed fitting, which matters in active data center environments where downtime is not an option. FRTSC12W6LBL fits deployments in data centers, telecommunications rooms, entrance facilities, and equipment distribution areas where pre-terminated fiber infrastructure demands a clean, modular pathway architecture.

Compatibility

This fitting is part of the Panduit Opti-Core® fiber raceway accessory family. It is designed for use with Panduit surface-mount fiber raceway channel systems that share the matching raceway profile width. Compatible deployment contexts include structured cabling installations in network infrastructure environments following ANSI/TIA-568 and ISO/IEC 11801 pathway standards. Verify the raceway channel width of your installed Panduit fiber optic cable management system matches the FRTSC12W6LBL fitting profile before ordering — Panduit offers multiple raceway width families, and tee fittings are not cross-compatible between them. This fitting is not intended for copper raceway systems or non-Panduit channel products.

Installation Notes

The split cover construction allows field installation over populated cable runs — no need to thread cables through the fitting during initial pull. Secure the base channel first, route cables, then snap the split cover in place. The 6-inch exit section provides a short governed transition to an adjacent raceway segment or drop point. Confirm exit orientation aligns with your pathway layout before mounting; horizontal tees are fixed geometry and cannot be field-modified. Intended for indoor, conditioned-space installation consistent with data center infrastructure and telecom room environments.
