Speco Technologies H24WHRLN2TB 24-Channel Wall Mount Hybrid Recorder
Overview
The H24WHRLN2TB is a 24-channel hybrid recorder designed for medium-scale surveillance systems that blend TVI analog and IP camera infrastructure. The unit delivers 8 dedicated TVI channels, 8 hybrid TVI/IP channels, and 8 IP channels in a single wall-mount chassis, making it suitable for facility expansions or phased migrations from analog to IP-based architectures. The 2TB internal storage provides retention capacity for standard business and industrial monitoring workflows—meaning 24/7 recording across all channels at typical frame rates without daily external storage swaps. NDAA certification ensures federal and defense-sector compliance for integrators supporting government or critical-infrastructure deployments.
Compatibility
The H24WHRLN2TB integrates with existing TVI camera installations while accepting ONVIF-compliant IP devices, supporting variable resolutions and frame rates. It accommodates legacy analog expansion alongside modern networked cameras, eliminating the need for complete system replacement when upgrading coverage. Wall-mount form factor fits standard 19-inch and flush-mount installation spaces common in server rooms, operations centers, and distributed facility monitoring stations. The hybrid channel architecture allows integrators to assign analog and IP inputs independently—8 TVI cameras to dedicated channels, 8 additional TVI cameras to shared hybrid slots, and 8 IP cameras to dedicated IP channels—without manual input type reconfiguration.
Installation Notes
Power input accepts regulated 12 VDC or 24 VDC, supporting both low-voltage and standard industrial power distribution schemes. Verify wall-mount surface load rating; the recorder and mounted bracket assembly require secure anchoring to prevent tipping under rack vibration or accidental contact. Mount to studs or use appropriate wall anchors rated for the unit's weight. Confirm PoE switch capacity if powering IP cameras directly from the same circuit; the recorder itself draws independent power, but simultaneous IP camera power draw may exceed typical PoE budgets on shared switches.
What's in the Box
Package contents not detailed in available evidence. Contact the manufacturer for an exact list of included mounting hardware, cables, and documentation.
