Panduit Smod 24-F HD Flex IND SM Diam Trnk 100FT - FY9UP77A001F100

Panduit FY9UP77A001F100 QuickNet HD Flex 24-Fiber Single-Mode Trunk Cable Assembly

Overview

The Panduit FY9UP77A001F100 is a 100-foot (30.5 m) pre-terminated fiber trunk cable from the Panduit QuickNet HD Flex family — engineered for structured cabling environments where installation speed and cable management density are both constraints. Designed for fiber trunk cable assemblies in data centers, telecommunications rooms, entrance facilities, and equipment distribution areas, it ships factory-terminated and tested so you can pull, route, and connect without field-terminating a single fiber.

The small-diameter, 24-fiber construction targets the space-conscious horizontal and backbone runs that define high-density data center cabling environments. Pre-terminated trunks eliminate the time and variability of field fusion splicing — when schedule or headcount is a limiting factor, pulling a tested assembly is the straightforward answer.

Key Features

• 24-Fiber Single-Mode Construction: Twenty-four single-mode fibers in a single trunk assembly gives you enough parallel paths to feed a full row of high-density patch panels or switches in a single pull — no need to manage multiple smaller cables or stage sequential pulls.
• Small-Diameter, HD Flex Profile: The QuickNet HD Flex small outer diameter reduces conduit fill and bend-radius concerns in tight pathways. In congested overhead trays or under-floor routes, that diameter difference has a real effect on how many circuits you can route through the same path.
• 100 ft / 30.5 m Factory Length: At 100 feet, the FY9UP77A001F100 covers the typical inter-rack or MDA-to-HDA span in most enterprise data halls without field-trimming or splicing. Length is fixed — verify your run distance before ordering to avoid slack management issues.
• Pre-Terminated, Factory-Tested Assembly: Every trunk ships tested to insertion loss specifications at the factory. You are not betting deployment success on a field tech's splice quality on a tight timeline — the performance is baked in.
• Rapid Deployment for Critical Infrastructure: Designed for data centers, telecom rooms, and entrance facilities where infrastructure build-out speed affects go-live dates. Pull, route, connect — no curing time, no OTDR confirmation loop before patching live.
• QuickNet HD Flex Sub-Brand: Part of Panduit's Panduit fiber infrastructure system architecture, designed to integrate with QuickNet cassettes and enclosures for end-to-end structured cabling.

Integration and Compatibility

The FY9UP77A001F100 is designed to integrate within the Panduit QuickNet ecosystem — specifically pairing with QuickNet HD modules, cassettes, and enclosures to form a complete end-to-end fiber channel. Verify the connector interface at each end against your installed or planned enclosure before ordering; trunk assemblies are not field-re-terminable without specialized equipment.

For installations in equipment distribution areas, confirm that bend-radius requirements at the trunk's termination points are maintained, particularly when routing into high-density patch panels where multiple trunks converge. Consult your structured cabling planning documentation for minimum bend radius compliance specific to this fiber type.

Frequently Asked Questions

Q: What is the fiber count and fiber type in the FY9UP77A001F100?

A: The FY9UP77A001F100 is a 24-fiber single-mode (SM) trunk cable assembly, as indicated by the product designation SMOD 24-F IND SM DIAM TRNK.

Q: What is the overall length of the FY9UP77A001F100?

A: The overall length is 100 feet (30.5 meters). This is a factory-fixed length — verify your run distance before ordering.

Q: What environments is the FY9UP77A001F100 designed for?

A: It is designed for data centers, telecommunications rooms, entrance facilities, and equipment distribution areas requiring pre-terminated fiber infrastructure for rapid deployment.

Q: Is the FY9UP77A001F100 field-terminable or re-terminable?

A: No — as a factory pre-terminated trunk assembly, it is not designed for field re-termination. The connectors are factory-installed and tested. Field modification would void factory test certification.

Q: Does the FY9UP77A001F100 integrate with other Panduit QuickNet components?

A: Yes — the FY9UP77A001F100 is part of the QuickNet HD Flex platform and is designed to integrate with Panduit QuickNet cassettes, modules, and enclosures as part of a complete structured cabling system.

James Everett

The FY9UP77A001F100 is one of those trunk assemblies that earns its place in a structured cabling project by eliminating a whole category of field risk. The 100-foot factory-terminated run means you are pulling a tested, performance-verified cable — not trusting a field fusion on a deadline. For data center builds where the cabling schedule is on the critical path, that distinction matters more than most people admit until they are troubleshooting insertion loss at 2 AM during commissioning.

Technical Highlights:

• 24-Fiber Single-Mode: Enough parallel paths in a single pull to serve a full high-density row — reduces pull count and cable tray congestion versus managing multiple smaller assemblies for the same fiber count.
• Small-Diameter HD Flex Profile: The reduced outer diameter directly affects conduit fill calculations and bend-radius compliance in tight overhead or underfloor pathways — a real constraint in retrofit data hall builds where pathways are already near capacity.
• 100 ft / 30.5 m Fixed Length: Covers standard MDA-to-HDA spans in most enterprise data halls. The fixed length is both the product's strength (factory-tested end-to-end) and its constraint — you need accurate run measurements before procurement, not after.

Deployment Considerations:

• Confirm cassette and enclosure interface compatibility before ordering — trunk connectors are factory-installed and not field-swappable. A mismatch discovered on-site means a new trunk, not a quick fix.
• Fixed-length trunks create slack management obligations. Budget for proper slack storage in your enclosure or pathway design; unmanaged slack on small-diameter cable is a long-term reliability issue at bend points.

The FY9UP77A001F100 is the right tool for structured data center MDA/HDA backbone runs and telecom room horizontal distribution where the priority is fast, reliable deployment using a tested factory assembly — not for point-to-point custom-length runs where a field-terminated solution would give you more flexibility.
