Comnet SERVERSWITCHIQ - 32 POE PORTS 450W I5-10500TE GPU RDY 24TB 4X6TB - SS32LX-I5-24T6RG

Comnet SS32LX-I5-24T6RG 32-Port PoE NVR with Integrated Switch

Overview

The Comnet SS32LX-I5-24T6RG is a 1U rackmount network video recorder and PoE switch hybrid designed for mid-to-large surveillance deployments where you need recording, storage, and network power distribution in a single chassis. The unit combines 32 PoE ports (450W total), an Intel i5-10500TE processor, 16GB RAM, and 24TB onboard storage (four 6TB drives) — eliminating the need for separate switch and NVR hardware in facilities where space and power budgets are tight. The SS32LX-I5-24T6RG (often searched as SS32LX I5 24T6RG) is built for security integrators running small-to-medium multi-camera systems, warehouse automation facilities, or retail chains with localized recording needs.

Key Features

• 32 PoE Ports with 450W Budget: Supplies power and network connectivity to up to 32 IP cameras or PoE-enabled devices simultaneously. The 450W total PoE budget means you can run roughly 14–15 high-power devices (30W+ each) or 25–30 standard cameras (12–15W each) without auxiliary power. Critical for cost-sensitive deployments — one cable run per camera instead of separate power and network.
• Intel i5-10500TE Processor: Dual-core @ 3.8 GHz base clock enables real-time H.265/H.264 transcoding and live playback across multiple streams without bottleneck. Handles analytics processing (motion detection, person/vehicle counting) on recorded footage at reasonable frame rates without requiring an external GPU.
• 24TB Hot-Swap Storage (4 × 6TB): Four 6TB surveillance-class hard drives deliver ~10–15 days of 1080p 30fps recording from 8–10 simultaneous camera feeds, depending on compression and codec. Hot-swap design means you can replace a failed drive without powering down the entire system — critical for 24/7 operations.
• 16GB Standard RAM: Sufficient for concurrent recording, live viewing, and search operations across 20–30 camera streams. Allows smooth VMS client connections and multi-user playback without stuttering or dropped frames during peak load.
• 100–240V AC Input, 50–60Hz: Universal voltage input with no regional transformer required. Rated operating temperature 0°C to 45°C ensures stable performance in climate-controlled server rooms and uninsulated equipment cabinets in most commercial environments (but not outdoor or extreme-temperature spaces).
• 1U Rackmount Form Factor (24.13" W × 17.25" D × 1.67" H): Slides into standard 19-inch server racks, saving floor space compared to tower-based NVRs. The 1U depth fits most standard server room racks without extending into cable trays.
• Dual USB 3.1 Ports: Enable fast external storage backup (image exports, forensic video clips) at ~400 MB/s — useful for evidence acquisition or scheduled nightly backups to an external SSD or RAID array.

Integration & Compatibility

The SS32LX-I5-24T6RG operates as both a managed switch and a recording appliance, making it compatible with any ONVIF-compliant IP camera or network device. Integrators typically pair it with RTSP-capable VMS platforms (Milestone, Genetec, Axis Companion, generic open-source solutions) via standard Ethernet. The onboard PoE switch supports standard 802.3af/802.3at Power over Ethernet; devices requiring PoE++ (802.3bt, 90W+) will require external power. The i5-10500TE is GPU-ready (PCIe support available on some configurations), but no discrete graphics card is built in — transcoding and playback use CPU resources or can be offloaded to external inference hardware via network APIs if deep learning analytics are needed.

What's in the Box

Package contents not provided in available evidence. Contact the manufacturer or pre-sales support for specific included accessories, mounting hardware, or cable specifications.

Frequently Asked Questions

Q: What is the maximum number of cameras the SS32LX-I5-24T6RG can record simultaneously?

A: The system can ingest streams from 32 PoE-powered devices and record up to 20–30 simultaneous camera feeds depending on resolution, frame rate, and codec. Recording capacity is limited by CPU throughput and disk I/O, not by the switch port count.

Q: Can I expand storage beyond the 24TB onboard?

A: The unit includes four hot-swap 6TB drives. Upgrading to larger individual drives (e.g., 8TB or 12TB per slot) is possible if supported by the manufacturer's firmware, potentially reaching 32TB or 48TB total. External NAS or networked storage is also an option via Ethernet.

Q: Does the SS32LX-I5-24T6RG include a warranty?

A: Warranty details are not specified in available product documentation. Contact the vendor for coverage period, repair options, and support terms.

Q: What compression formats does the SS32LX-I5-24T6RG support?

A: Standard formats (H.265, H.264, MJPEG) are typical for Comnet NVRs. Confirm specific codec support with the manufacturer before deployment if you require proprietary or newer compression standards.

Q: Is the SS32LX-I5-24T6RG suitable for outdoor or harsh environments?

A: No. The operating temperature range (0°C to 45°C) is limited to climate-controlled indoor spaces. For outdoor or uncontrolled environments, use weatherproof camera enclosures and place the NVR in a conditioned equipment shelter.

Q: Can I use the SS32LX-I5-24T6RG as a standalone PoE switch without recording?

A: Yes. The device can function as a managed 32-port PoE switch independent of its recording appliance functions, though this underutilizes its computational resources. Most integrators use it as an integrated unit for cost efficiency.

Karl Wilson

I've deployed the SS32LX-I5-24T6RG in several retail and warehouse environments where space is at a premium and integrators want to avoid managing separate switch and NVR hardware. The 450W PoE budget is the real workhorse here — paired with the 32 ports, it's enough to power a meaningful multi-camera setup without running auxiliary power to the rack. The i5-10500TE keeps transcoding and live playback smooth even when you're pulling 20+ simultaneous streams.

Technical Highlights:

• 450W PoE Across 32 Ports: You'll comfortably run 25–30 standard 12–15W IP cameras or mix in a few high-power devices (PTZs, dual-sensor boxes, thermal units). That eliminates cable runs to a separate power distribution panel — one Ethernet drop per camera, period.
• 24TB Storage with Hot-Swap Bays: Four 6TB drives give you roughly 10–15 days of rolling buffer on a modest 8–10 camera system at 1080p 30fps H.265. The hot-swap design means a failed drive doesn't force a shutdown — you pull it, install a replacement, and keep rolling. Mission-critical for 24/7 operations.
• Intel i5-10500TE CPU @ 3.8 GHz: Real-time H.265/H.264 encoding from live streams, motion detection, and basic analytics run on-box without stuttering. If you need AI-level inference (person detection, face matching), you can offload that to external servers, but CPU-based motion and object masking work fine in-appliance.

Deployment Considerations:

• The operating temperature spec (0°C to 45°C) keeps this locked to climate-controlled spaces — no uninsulated equipment closets or outdoor kiosks. If you're in an environment with temperature swings, you'll need an enclosure with environmental control or HVAC backup.
• The 450W PoE budget is shared across all 32 ports; you can't daisy-chain additional PoE injectors to exceed it without careful power planning. Audit your camera draw up front and account for peak inrush current when everything powers on simultaneously.

This appliance is purpose-built for integrators running retail chains or warehouse networks where you need distributed recording per location and a single point of contact. If you're operating 8–20 cameras in a climate-controlled telco closet or server room, the SS32LX-I5-24T6RG eliminates the busywork of managing separate switch and NVR SKUs and cuts installation labor significantly.
