SDC 805AL 6 AMP Key Switch Assembly

Overview

The SDC 805AL is a 6 AMP key switch assembly designed for electromagnetic lock and door strike control in OSDP-compliant access control installations. The 1/4" thick aluminum construction with 1/4" port connections fits standard commercial door hardware mounting. Deploy this where you need a hardwired switch control point integrated into a distributed access control network — typically upstream of an access control panel managing credential verification and strike/lock logic.

Compatibility

The 805AL operates within OSDP (Open Supervised Device Protocol) environments, making it compatible with access control panels and readers supporting OSDP-compliant devices. It works with proximity and keypad reader types operating on NFC/13.56MHz frequency bands, allowing flexible reader selection across standard enterprise access control architectures. The 6 AMP rating accommodates typical electromagnetic lock and door strike applications found in commercial door hardware installations. Verify your access control panel's OSDP implementation and reader credential protocol before integration.

Installation Notes

Mount using the 1/4" port connections to your door frame or strike mounting bracket. The 1/4" thick aluminum housing provides structural rigidity for direct hardware attachment. Ensure your access control panel and reader support OSDP communication and NFC/13.56MHz credential frequencies. The 6 AMP rating should be verified against your specific lock/strike power draw — if your door hardware pulls more than 6 amps under normal operation, this assembly is undersized for the application.
