Panduit PN10-6R-L Concise Descriptor

Overview

The Panduit PN10-6R-L is a heavy-duty ring terminal designed for terminating 12-10 AWG wire. It features six studs, providing a robust connection point for multiple conductors or secure attachment to busbars and equipment terminals. This terminal is critical for ensuring reliable power and signal distribution in industrial environments, including those supporting surveillance systems where stable power is paramount.

Compatibility

This terminal is designed for use with 12-10 AWG stranded or solid copper conductors. It is compatible with stud sizes up to #10 (metric M5). Its primary application is in electrical distribution panels, power supplies, and equipment requiring secure, multi-point grounding or power connections. For surveillance installations, it ensures a stable ground or power connection to NVRs, switch power inputs, or distributed power systems.

Installation Notes

For optimal performance and safety, use Panduit crimping tools (e.g., CT-900, CT-920, CT-930, CT-940CH) with the appropriate die set for 12-10 AWG wire. Ensure the terminal is crimped securely to the wire, providing a low-resistance connection. The six studs require appropriate M5 or #10 sized nuts and washers for secure mounting. Torque specifications should follow electrical code or equipment manufacturer guidelines.
