Vertiv VP5N50A4 Switched Rack PDU
Overview
The Vertiv VP5N50A4 is a 50A, 208V Delta switched rack power distribution unit designed for high-density IT environments. It provides remote on/off switching for individual outlets, enabling granular power control and remote reboot capabilities for connected equipment. This unit is ideal for data centers and server rooms where precise power management and uptime are critical. The VP5N50A4 offers 14.4kW capacity and mounts vertically in standard 48U racks, optimizing space utilization. It supports 20A input and provides 24 individually controlled 5-20R outlets.
Compatibility
This PDU is designed for use in standard 19-inch server racks. It requires a 208V Delta power source and is compatible with IT equipment utilizing standard NEMA 5-20P plugs. The unit is suitable for deployment with most server, network, and storage hardware requiring 20A or less per outlet. It is also compatible with Vertiv's suite of data center infrastructure management (DCIM) solutions for enhanced monitoring and control.
Installation Notes
The VP5N50A4 features a vertical mounting design, requiring approximately 48U of rack space. It connects to a 208V Delta power source via a hardwired connection or a compatible plug (check specific model variant). Ensure the power source can supply a minimum of 50A. The unit is RoHS, UL & c-UL Listed for safety compliance in North American installations. FCC Part 15 Class A compliance ensures it does not cause harmful interference in commercial environments.
What's in the Box
- 1x Vertiv VP5N50A4 Switched Rack PDU
- 1x Vertical Mounting Kit
- 1x Power Cord
