Vertiv Rpdu Switched Outlet Level Monitoring EC 30A 120/208V WYE 8.6KW Horizontal - VP7N32A2

Vertiv VP7N32A2 Switched Outlet-Level Monitoring rPDU — 30A, 3-Phase, 120/208V

Overview

The Vertiv VP7N32A2 is a horizontally-mounted, three-phase rack PDU that combines outlet-level switching with real-time current, voltage, and power monitoring — giving data center and IT teams precise control over every load in the rack without requiring physical access. Rated at 30A on a NEMA L21-30P input plug and delivering up to 8.6kW across a 120/208V WYE configuration, the VP7N32A2 is built for high-density server and network equipment racks where granular power management matters.

With 24 outlets (C13 and C19 mix) and an integrated LCD display, this unit belongs in rack power distribution environments where you need both the visibility to catch power anomalies and the ability to remotely cycle individual outlets without dispatching a technician. The Vertiv rPDU line is designed around enterprise-class management depth, and this model delivers that in a horizontal 0U form factor.

Key Features

• Outlet-Level Switching: Each of the 24 outlets can be independently switched on, off, or power-cycled via the network management interface — critical for remote hands-free reboot of locked-up servers or staged power sequencing during maintenance windows. No more truck rolls for a frozen appliance.
• Three-Phase 30A / 8.6kW Input: The NEMA L21-30P input and 120/208V WYE configuration let this unit draw balanced three-phase power from your PDPs, distributing load across phases and maximizing usable capacity in dense racks. At 8.6kW usable, it fits comfortably under a standard 10kW circuit with headroom.
• 24 Outlets — C13 + C19 Mix: A combination of IEC C13 (standard 1U/2U server) and C19 (high-draw devices like blade chassis, high-density switches, UPS outputs) outlets means you can mix workloads in a single rack without adapters. Verify your exact C13/C19 split against your rack layout before ordering.
• Current, Voltage, and Power Monitoring per Outlet: Real-time telemetry at the outlet level — not just aggregate bank readings — means you can track watt-hours per device, set per-outlet current thresholds, and catch a failing PSU drawing abnormal current before it becomes an outage. This is the spec that separates outlet-level units from bank-level monitored PDUs.
• LCD Display: Local LCD readout provides at-a-glance power data without requiring a network connection — useful during initial commissioning, physical audits, or when your management network is the thing that's down.
• Enterprise Management Protocol Stack: SNMP v1/v2c/v3, HTTPS, SSH, RADIUS, LDAP, TACACS+, Modbus TCP, Syslog, and NTP are all supported out of the box. This isn't a consumer-grade web interface — it integrates cleanly into DCIM platforms, SNMP-based NMS tools, and AAA infrastructure. TACACS+ and RADIUS mean you're not managing local credentials on 40 PDUs.
• IPv4 and IPv6 Dual-Stack: Native IPv6 support matters in government, higher-ed, and enterprise environments already running dual-stack. No workarounds, no IPv4-only limitations.
• 1x RJ-45 Ethernet + 1x USB + 1x Serial: The RJ-45 port handles all IP management. The USB port supports firmware updates and local configuration. The serial console port provides out-of-band access when the network interface is unreachable — a genuine safety net during network incidents.
• 3-Meter Input Cable: The 3m (approximately 10 ft) attached input cord reaches floor-level power panels from mid-rack or top-of-rack mount positions without extension — practical in most two-post and four-post open-frame deployments.
• 50/60 Hz, 100–240V Input Range: The broad input frequency and voltage range (100–120V / 200–240V) means the same unit works in North American 208V three-phase environments and international 230V installations — useful if you operate multi-region data centers with standardized PDU procurement.

Integration and Compatibility

The VP7N32A2 integrates into standard network management infrastructure via SNMP v3 — compatible with platforms like SolarWinds, PRTG, Nagios, and most enterprise DCIM tools that support PDU management over SNMP. Modbus TCP support extends compatibility to building management systems (BMS) and industrial control environments. LDAP and RADIUS/TACACS+ authentication integrates with Active Directory and existing AAA servers, eliminating per-device local account management at scale.

For teams evaluating Vertiv's broader power management portfolio, the VP7N32A2 fits into deployments alongside Vertiv UPS systems and environmental monitoring solutions, enabling consolidated power chain visibility from the UPS input through individual rack outlet. Pair with a compatible rack enclosure rated for horizontal PDU mounting to complete the installation.

Frequently Asked Questions

Q: What is the input plug type and power rating for the VP7N32A2?

A: The VP7N32A2 uses a NEMA L21-30P input plug, rated at 30A, 120/208V WYE three-phase, with a maximum capacity of 8.6kW. The attached input cord is 3 meters long.

Q: Does the VP7N32A2 support per-outlet switching, or only bank-level switching?

A: Per-outlet switching — each of the 24 outlets can be individually controlled (on/off/reboot) via the network management interface. This is distinct from bank-level switched PDUs, which only switch groups of outlets together.

Q: What network protocols does the VP7N32A2 support for remote management?

A: Supported protocols include SNMP v1/v2c/v3, HTTPS, HTTP, SSH, RADIUS, LDAP, TACACS+, Modbus TCP, Syslog, NTP, DHCP, IPv4, and IPv6. It integrates with SNMP-based NMS and DCIM platforms, and supports enterprise AAA authentication.

Q: What outlet types does the VP7N32A2 provide?

A: The unit provides a mix of IEC C13 and IEC C19 outlets across its 24 total positions. C13 outlets suit standard 1U/2U servers; C19 outlets handle higher-draw equipment like blade chassis, dense switches, and UPS bypass outputs.

Q: Is the VP7N32A2 suitable for international data centers outside North America?

A: The input accepts 100–120V and 200–240V at 50 or 60 Hz, making it compatible with both North American 208V three-phase and international 230V three-phase power environments, provided the appropriate input receptacle and feed are available.

Q: What local interface does the VP7N32A2 provide if the network is unavailable?

A: The unit includes an LCD display for local power readout, a USB port for local configuration and firmware updates, and a serial console port for out-of-band management access when the Ethernet network interface is unreachable.

Karl Wilson

The VP7N32A2 is the unit I reach for when a client needs outlet-level switched control and real monitoring — not just monitoring — on a three-phase horizontal PDU. The combination of per-outlet current, voltage, and power telemetry with independent outlet switching on all 24 positions is a meaningful capability gap over bank-switched or purely monitored alternatives. At 30A / 8.6kW on a NEMA L21-30P feed, it fits standard three-phase PDP circuits without any derating gymnastics.

Technical Highlights:

• SNMP v3 + TACACS+/RADIUS: With SNMP v3 encryption and TACACS+ or RADIUS AAA integration, you're not punching credential holes in your security posture to manage PDUs. Push authentication to your existing AAA infrastructure and audit every outlet action centrally — this matters in PCI and SOC 2 environments.
• Modbus TCP: The Modbus TCP support means the VP7N32A2 can report into building management systems and DCIM platforms that don't speak SNMP natively. In colocation and campus environments where BMS integration is required by facilities, this protocol saves a translator appliance.
• 3-Meter Input Cord: The 3m cord sounds mundane until you're routing cable in a 42U open-frame rack with a floor-level distribution panel. It reaches without an extension on most deployments — and extensions on PDU inputs are one of those things facilities managers will flag on a walk-through.

Deployment Considerations:

• Confirm your exact C13/C19 outlet count against your device mix before ordering — the spec lists 24 outlets total across both types, but the precise split matters if you have multiple C19-hungry blade chassis in the same rack.
• The unit is rated 0U horizontal mount; verify your rack has the horizontal PDU mounting brackets or tooled rails at the appropriate position before the PDU ships — retrofitting bracket mounts after the fact in a live rack is tedious.

This unit is a strong fit for enterprise colocation deployments, financial data centers, or any environment where remote outlet reboot, per-outlet energy metering, and integration with existing AAA and DCIM infrastructure are non-negotiable requirements rather than nice-to-haves.
