Vertiv Rpdu Basic Surge 20A 120V 1.9KW - 11266VH

Vertiv 11266VH Basic Surge 20A 120V Horizontal Rack PDU

Overview

The Vertiv 11266VH is a 0U horizontal rack power distribution unit designed for IT closets, small server rooms, and edge deployments where you need reliable 20A single-phase power distribution across six NEMA 5-20R outlets without consuming a rack unit. It accepts a NEMA L5-20P twist-lock input at 100–120V/20A and provides 1.9kW of capacity — enough to support a handful of 1U servers, network switches, or security appliances running simultaneously. If you're speccing power distribution for a rack PDU deployment where physical space is tight and load management is straightforward, the 11266VH covers the basics without overcomplicating the build.

Vertiv's broader Vertiv power infrastructure line spans managed, metered, and basic PDU tiers — the 11266VH sits at the entry level, deliberately. No per-outlet switching, no remote monitoring, no display. What it does offer is surge protection and overcurrent protection in a horizontal form factor that mounts cleanly to a 0U position on the side rail of most standard racks. For environments where a network admin or integrator just needs dependable outlet capacity and basic protection, this unit is sized and priced accordingly.

Key Features

• 20A/120V Single-Phase Input via NEMA L5-20P: The twist-lock plug ensures the input connection stays secured under vibration or accidental contact — a real issue in dense rack environments where cable management gets crowded. Pair this with a dedicated 20A circuit breaker for proper upstream protection.
• Six NEMA 5-20R Outlets at 1.9kW Total Capacity: Six standard receptacles handle mixed loads — think 1U switches, NVRs, or small servers. At 1.9kW total, plan your connected load to stay under 80% of nameplate (roughly 1.5kW continuous) to avoid tripping the overcurrent protection during startup inrush.
• 0U Horizontal Mounting: Zero rack units consumed means you keep all 1U, 2U, and 4U positions available for active equipment. Horizontal orientation suits wide rack side-rail mounting, distributing outlets across the rear panel for shorter power cord runs to adjacent equipment.
• Overcurrent Protection: Built-in overcurrent protection responds to load spikes before they damage connected equipment or trip an upstream breaker. For a rack supporting security recording infrastructure or edge networking gear, this is the baseline protection threshold you need from a rack power infrastructure unit at this price point.
• Surge Protection: Surge suppression absorbs transient voltage events on the AC line — relevant in facilities where HVAC compressors, elevators, or industrial equipment share the electrical infrastructure. Not a substitute for a UPS on mission-critical loads, but meaningful as a first line of defense for secondary equipment.
• 3.05m (10 ft) Input Cable: A 10-foot cord provides enough reach from a floor-level PDU or side-mounted position to a wall outlet or in-rack UPS — eliminates the need for an extension cord in most standard rack configurations.
• 50/60 Hz Compatible: Dual-frequency acceptance means the same unit works across North American grid standards without modification. Useful for deployments across multiple facilities or in mixed-infrastructure environments.
• Power LED Indicator: A single power LED confirms the unit is energized at a glance — straightforward confirmation without the complexity of a display or remote monitoring interface.

Integration and Compatibility

The 11266VH is a passive distribution device — no network interface, no SNMP agent, no management overhead. It integrates with any standard rack that supports 0U horizontal PDU mounting. The NEMA L5-20P input is compatible with most UPS output panels and dedicated circuit outlets spec'd for 20A twist-lock termination. Downstream, the six NEMA 5-20R receptacles accept any standard North American plug, making it broadly compatible with networking gear, recording hardware, and general IT equipment. This unit is not suitable for 208V or three-phase environments — confirm your facility power is single-phase 100–120V before deployment.

Frequently Asked Questions

Q: What is the maximum load I should run on the Vertiv 11266VH continuously?

A: The 11266VH is rated at 20A/120V (1.9kW). Best practice is to keep continuous load at or below 80% of nameplate capacity — roughly 16A or 1.5kW — to avoid thermal stress on the unit and minimize the risk of tripping the overcurrent protection during inrush events.

Q: Does the 11266VH include a remote management interface or outlet-level switching?

A: No. The 11266VH is a basic PDU with no network interface, no SNMP, and no per-outlet switching or metering. It provides passive distribution with surge and overcurrent protection only. If you need remote monitoring or outlet control, consider a metered or switched PDU in Vertiv's lineup.

Q: What input plug does the 11266VH use, and is it compatible with standard UPS output panels?

A: The 11266VH uses a NEMA L5-20P twist-lock plug. This is compatible with UPS units and facility circuits spec'd for 20A twist-lock output at 120V. Confirm your UPS or wall circuit matches L5-20P before ordering.

Q: Can the 11266VH be rack-mounted horizontally in a standard 19-inch rack?

A: Yes. The 11266VH is designed as a 0U horizontal mount, meaning it installs along the side rail or rear channel of a standard rack without occupying any rack unit positions. This preserves full rack height for active equipment.

Q: Is the 11266VH compatible with 208V or international voltage standards?

A: No. The 11266VH is rated for 100–120V single-phase input only. It is not suitable for 208V, 240V, or three-phase power environments. Verify your facility power matches 100–120V before deployment.

James Everett

The 11266VH is a unit I reach for when an IT closet or edge rack needs clean 20A distribution without the overhead of a managed PDU. The NEMA L5-20P twist-lock input is the detail that matters most in practice — standard NEMA 5-20P plugs can be pulled loose by cable weight or accidental contact, and in a rack that isn't checked daily, that's a silent failure waiting to happen. The twist-lock eliminates that risk at the source.

Technical Highlights:

• 20A Overcurrent Protection: The built-in overcurrent protection trips before an upstream breaker does — keeps a single equipment fault from taking down the whole circuit and forces a local reset rather than a panel walk.
• Six NEMA 5-20R Outlets at 1.9kW: Enough capacity for a typical 4–6 device edge stack — a PoE switch, NVR, firewall, and a spare — as long as you respect the 80% continuous load ceiling of roughly 1.5kW.
• 3.05m Input Cord: The 10-foot cord is deliberately long — it handles the vertical drop from a side-mounted PDU position to floor-level UPS output panels without a cord extension, which is a code compliance point worth noting in commercial installations.

Deployment Considerations:

• The NEMA L5-20P input requires a matching 20A twist-lock receptacle upstream — verify your UPS output panel or circuit outlet matches before the unit ships to site. A mismatch discovered on installation day adds delay.
• This is surge protection only, not a UPS substitute. For any equipment where an unplanned power interruption causes data loss or service downtime — NVRs, access control panels, network switches — put a UPS between the wall and this PDU, then feed the 11266VH from the UPS output.

The 11266VH is the right call for small edge racks in branch offices, IDF closets, or security equipment rooms where a managed PDU's cost and complexity aren't justified, but you still want overcurrent protection and surge suppression on a 20A twist-lock feed.
