Vertiv Rpdu Basic Standard 20A 208V 3.3KW - 11856VH

Vertiv 11856VH Basic Standard PDU

Overview

The Vertiv 11856VH is a basic, single-phase rack PDU designed for vertical, 0U mounting within standard server racks. It provides 30 AC outlets, a mix of C13 and C19 couplers, to distribute power to IT equipment. This unit is suitable for data center and network closet environments where straightforward power distribution is required, featuring a NEMA L6-20P plug for connection to a 20A, 208V circuit.

Compatibility

This PDU is designed for use with standard 19-inch server racks and cabinets. It connects to a 20A, 208V power source via its NEMA L6-20P plug. The unit supports a maximum load capacity of 3.3kW. It is compatible with a wide range of IT equipment requiring C13 or C19 power connections. Its basic functionality means it integrates with any rack system that can accommodate its vertical mounting and power input requirements.

Installation Notes

The 11856VH mounts vertically within a 0U space in standard server racks, requiring no rack unit (RU) space. It is designed for connection to a 200-240V AC input, with a 50/60 Hz frequency. The integrated 3-meter power cord connects to a NEMA L6-20R receptacle. Operating temperature range is 0-60°C. It is RoHS Compliant and UL & c-UL Listed 60950.
