Vertiv Rpdu Basic Standard 15A 120V 1.4KW - 29047VH

Vertiv 29047VH Basic Standard 15A 120V 1.4KW

Overview

The Vertiv 29047VH is a basic rack power distribution unit (PDU) designed for standard IT deployments. It provides 10 NEMA 5-15R outlets, allowing you to power multiple devices from a single input source within a server rack. This unit is suitable for environments where basic power distribution is required without advanced monitoring or switching capabilities. The 29047VH model is configured for 120V input and supports up to 1.4kW of power draw, making it appropriate for lower-density rack configurations.

Compatibility

This PDU is compatible with standard 19-inch server racks and cabinets. It utilizes a NEMA 5-15P plug, which connects to typical 120V wall outlets or facility power circuits rated for 15A. It is designed to power standard IT equipment such as servers, network switches, and patch panels that utilize NEMA 5-15R power cords.

Installation Notes

The Vertiv 29047VH is designed for vertical mounting within a standard 19-inch rack. It requires a 15A, 120V power source. Ensure the total power draw of connected equipment does not exceed the PDU's 1.4kW capacity to prevent overloading. The unit's physical dimensions are optimized for rack integration, typically occupying 0U or minimal rack space depending on the mounting orientation.

What's in the Box

• 1x Vertiv 29047VH Basic Rack PDU
• 1x Vertical Mounting Bracket Kit
