APC by Schneider Electric Rack PDU 2G Switched Zerou 30A 120/208V (16) 5-20R (7) - AP8970GRNX874

APC by Schneider Electric AP8970GRNX874 Switched Zero-U Rack PDU 2G

The APC by Schneider Electric AP8970GRNX874 is a second-generation switched rack power distribution unit built for dense IT and security equipment enclosures where per-outlet power control and zero rack-unit footprint matter. The Zero-U form factor mounts vertically along the inside rail of a standard rack, preserving all horizontal 1U–4U slots for revenue-generating equipment — a meaningful distinction in fully loaded surveillance or network racks where space is the hard constraint.

Overview

Rated at 30A on a 120/208V input, the AP8970GRNX874 delivers enough headroom for high-density loads — mixed NVRs, PoE switches, servers, and storage arrays sharing a single distribution point. The (16) 5-20R receptacles cover the standard NEMA 5-20 devices that dominate mid-range IT and security installations, while the additional seven outlets extend coverage to higher-draw or specialized equipment in the same enclosure.

Key Features

• Switched Per-Outlet Control: Individual outlet switching lets you power-cycle a locked-up NVR or reboot a hung switch remotely — no physical access to the rack required. In distributed surveillance deployments with remote equipment rooms, this eliminates truck rolls for routine reboot events.
• Zero-U Vertical Form Factor: Mounts on the rack's vertical rail channel, consuming zero horizontal rack units. In a 42U enclosure running 40U of active equipment, this is the only PDU architecture that doesn't force a trade-off between outlets and usable rack space.
• 30A / 120/208V Input Rating: Supports both single-phase 120V and 208V input configurations, giving installers flexibility across different facility power environments without stocking separate SKUs for each voltage tier.
• 2G Network Management: The second-generation network management card provides remote access, outlet-level switching, and environmental monitoring integration — compatible with APC's EcoStruxure IT and legacy InfraStruXure management platforms used in enterprise data centers and large physical security operations centers.
• (16) NEMA 5-20R Receptacles: The 5-20R outlet type covers the overwhelming majority of rack-mount security and IT gear — NVR appliances, PoE switches, servers — without requiring plug adapters or special input cords on connected equipment.
• Rack PDU 2G Platform: The 2G generation supports network card hot-swap, daisy-chain network connectivity between PDUs, and SNMP/HTTP/HTTPS management — reducing per-PDU IP address requirements in large deployments and simplifying network segmentation for OT/security networks.

Integration & Compatibility

The AP8970GRNX874 integrates with APC's EcoStruxure IT platform for centralized power monitoring and alerting across multiple racks. The 2G management card supports standard SNMP traps, allowing integration with enterprise NMS platforms (SolarWinds, PRTG, Nagios) and physical security management systems that monitor infrastructure health alongside camera and access control status. The NEMA 5-20R outlet configuration is directly compatible with standard rack-mount NVRs, managed PoE switches, and server appliances without cord modifications.

Frequently Asked Questions

Q: What is the input plug type on the AP8970GRNX874?

A: The AP8970GRNX874 is rated for 30A at 120/208V input. The specific input plug type is not confirmed in available evidence — verify the input cord configuration directly with the manufacturer or your distributor before ordering to ensure compatibility with your facility's power source.

Q: Does the Zero-U form factor fit all standard racks?

A: Zero-U PDUs mount vertically on the interior rail of standard EIA-310 compliant racks. Compatibility depends on your rack's rail channel design. APC Zero-U PDUs are designed for use with APC NetShelter and compatible third-party enclosures — confirm your rack's vertical mounting channel dimensions before specifying.

Q: Can I manage the AP8970GRNX874 remotely?

A: Yes. As a Switched 2G PDU, the AP8970GRNX874 includes a network management card that supports remote outlet switching, monitoring, and SNMP integration. Individual outlets can be powered on, off, or cycled remotely via the network interface.

Q: What is the outlet configuration on the AP8970GRNX874?

A: The AP8970GRNX874 provides (16) NEMA 5-20R outlets plus (7) additional receptacles, for a total of 23 outlets. The 5-20R outlets accept standard NEMA 5-20P plugs used on most rack-mount IT and security equipment.

Q: Is the AP8970GRNX874 suitable for 208V three-phase environments?

A: The unit is rated for 120/208V input. Whether it supports single-phase 208V, split-phase, or both depends on the specific input configuration — confirm with the manufacturer's datasheet for your facility's power topology before deploying in a 208V environment.

Karl Wilson

The AP8970GRNX874's Zero-U vertical mount is the spec I'd highlight first for anyone building out a dense surveillance or security rack — it's the difference between fitting 40U of NVRs, switches, and compute into a 42U enclosure versus giving up 1–2U to the PDU itself. At 30A on a 120/208V feed, there's real headroom for high-draw rack configurations without hitting the 80% continuous load threshold that trips breakers under sustained NVR recording loads.

Technical Highlights:

• Per-Outlet Switching (2G): Remote power cycling at the individual outlet level eliminates physical access for NVR or switch reboots — critical in unmanned equipment rooms at remote surveillance sites.
• 30A Input Rating: Running at the NEC-recommended 80% continuous load ceiling puts practical usable capacity at ~24A — enough for 8–12 high-draw rack-mount devices simultaneously on a single PDU circuit.
• 16x NEMA 5-20R Outlets: Covers standard rack-mount security gear natively — no plug adapters, no cord whips, no additional hardware between the PDU and connected equipment.

Deployment Considerations:

• Zero-U vertical mounting requires a rack with a compatible interior vertical mounting channel — verify your enclosure's rail spec before ordering, particularly with non-APC third-party racks.
• The 7 additional outlets beyond the 16x 5-20R bank are not spec-confirmed in available evidence — identify the outlet type and amperage rating for those positions before assigning high-draw devices to them.

Best fit for enterprise physical security operations centers and large surveillance equipment rooms running mixed NVR, PoE switch, and server loads in fully populated racks where Zero-U is the only viable PDU architecture.
