PioneerPOS STLH-PSEA11301K 150W Power Supply

Overview

The STLH-PSEA11301K is a 150W switching power supply rated for dual input voltage (110–220V AC), designed to power PioneerPOS M5 point-of-sale and surveillance systems. At 150W capacity, this supply handles multi-device configurations—cash drawer, barcode scanner, PIN pad, and IP cameras—without undersizing or thermal stress. The wide input voltage range means a single unit works across North American (110V) and international (220V) installations without a step-down transformer, reducing BOM cost and installation overhead.

Compatibility

This supply is engineered for PioneerPOS M5 systems and related peripherals that draw up to 150W aggregate load. Verify your specific M5 configuration draws within this envelope—camera arrays with active IR, heated domes, or integrated NVR functions may approach or exceed this limit. If your deployment includes multiple high-current draws (e.g., 4+ PoE cameras, heated outdoor housings, redundant readers), confirm total current before installation.

Installation Notes

Input accepts both 110–220V AC; no voltage selector switch needed—the supply auto-detects and adjusts. Confirm mains voltage and frequency (50/60Hz) at the installation site. Route the AC input cord through conduit or cable management to avoid pinching. The 150W rating assumes ambient temperature below 40°C; in hotter environments, derate by 10–15% per 5°C above that threshold to preserve component life. Do not leave the supply unloaded (0W output) for extended periods; brief idle cycles are normal, but continuous operation below 20W load may reduce lifespan.
