Height:
22.52 in (57.2 cm)
Width:
18.58 in (47.2 cm)
Depth:
27.09 in (68.8 cm)
Net Weight:
392.82 lb(US) (178.18 kg)
Mounting Mode:
Rack-mounted
Power Module Slots Free:
1
Power Module Slots Filled:
2
Network Frequency:
45...65 Hz auto-sensing
Input Connectors:
1 hard wire 4-wire
Input Voltage Limits:
96...138 V line to neutral
Input Harmonic Distortion:
Less than 7 %
Maximum Configurable Power Watts:
6400 W
Output Harmonic Distortion:
Less than 5 %
Output Frequency:
47...63 Hz sync to mains
Output Frequency Tolerance:
+/- 0.1 %
Crest Factor:
Up to 5 : 1
UPS Type:
Double conversion online
Wave Type:
Sine wave
Bypass Type:
Internal bypass
Efficiency:
90 %
Maximum Output Current:
37 A
Maximum Configurable Power VA:
8000 VA
Product Certifications:
CSA, FCC part 15 class A, OSHPD, UL 1778
Operating Temperature:
32…104 °F (0…40 °C)
Operating Relative Humidity:
0…95 %
Operating Altitude:
0...10000 ft
Storage Temperature:
5…113 °F (-15…45 °C)
Storage Relative Humidity:
0…95 %
Storage Altitude:
0…15000 ft
Acoustic Level:
62 dBA
Heat Dissipation:
3707 Btu/h
Free Slots:
1
Battery Recharge Time:
3 h
Battery Charger Power:
574 W
Battery Life:
3…5 year(s)
Rated Power Watts:
6400 W
Rated Power VA:
8000 VA
Output Connector Types:
4 NEMA L5-20R, 2 NEMA L14-30R
Output Connector Hard Wire:
1
Number of Rack Units:
13U
Battery Type:
Lead-acid battery
Number of Battery Filled Slots:
2
Number of Battery Free Slots:
0
Warranty:
2 years repair or replace
