Pelco IMF-PNL 2x2ft Ceiling Panel Fisheye White
The Pelco IMF-PNL is a reinforced metal ceiling panel designed for flush in-ceiling mounting of Pelco IMF Series fisheye cameras in standard drop ceiling grid installations. This 2ft x 2ft panel replaces a standard ceiling tile, providing structural support and a precision cutout for secure, professional camera installation.
Key Features
- Metal construction with reinforced design to support camera weight without sagging or structural degradation
- Precision-engineered cutout for flush mounting of IMF Series fisheye cameras
- Pantone 427C white finish for seamless integration with standard office and commercial ceilings
- Compatible with standard 2ft x 2ft T-bar grid systems only
- NDAA Section 889 compliant for government and regulated facility deployments
- Enables full 360° or 180° panoramic coverage from a single ceiling-mounted point
Technical Specifications
- Dimensions: 2ft x 2ft
- Compatibility: Pelco IMF Series fisheye cameras only
- Grid Type: Standard T-bar drop ceiling grids
- Color: Pantone 427C white
- Material: Reinforced metal
- Warranty: 5-year warranty
Installation Requirements
Before ordering, confirm that the cutout dimensions match your specific IMF model's flange size, and verify your plenum depth accommodates the full fisheye camera body. For non-fisheye dome cameras or grey panel options, alternative models (DCLPNL-1001, CLPNL-1001, or CLPNL-1011) may be required.
Applications
Ideal for commercial facilities, corporate offices, retail environments, and industrial installations requiring unobtrusive ceiling-mounted panoramic surveillance with minimal aesthetic impact.
