Pelco IDL302-FXI 3MP Modular Camera Head
The Pelco IDL302-FXI is a 3MP modular camera imager head engineered for integration into Pelco's Sarix modular housing system. By decoupling the imaging electronics from the environmental enclosure via the FXI interface, this head enables field-swappable sensor upgrades and rapid maintenance without breaking conduit seals, disturbing cabling, or draining NVR uptime—a genuine operational advantage in multi-camera facilities where housing reuse across deployments is standard practice.
Key Features
- 3MP Resolution at 30 fps: 2048 × 1536 pixel output with full frame rate delivers forensic-grade detail on faces and vehicle registrations from moderate distances without bitrate bloat.
- H.265 and H.264 Codec Support: H.265 reduces storage and bandwidth 40-60% versus H.264 on equivalent quality; multi-codec fallback ensures compatibility with legacy NVR platforms.
- ONVIF Profile S and Profile T: Vendor-neutral streaming and advanced metadata (motion masks, line crossing) work across Genetec, Milestone, Avigilon, and ExacqVision without proprietary middleware.
- 0.1 lux Low-Light Sensitivity with WDR: Day/night IR capability and forensic WDR handle backlit doorways, vehicle headlights, and dawn/dusk scenes without external lighting.
- PoE Class 3 Power: Standard 802.3af PoE compliance — plugs into any managed switch without dedicated breaker infrastructure; <13W typical draw allows dense deployments on shared injection.
- IP66 Rating, -40°C to +60°C Operating Range: Sealed against dust and high-pressure spray; thermal stability across extreme climates (outdoor arctic mounts to desert enclosures) without performance drift.
- 3.7mm F2.5 Fixed Lens: Wide field-of-view geometry suited to short-throw retail and office installations; low aperture passes maximum light to the sensor in dim conditions.
- microSD Local Recording: Onboard card slot enables failover recording if NVR link drops — critical for mission-critical retail and access-control tie-ins.
- 5-Year Manufacturer Warranty: Covers defects in materials and workmanship across the full temperature and duty-cycle envelope.
The modular architecture is the real differentiator. Unlike fixed-form cameras, the IDL302-FXI sensor head threads into any compatible Pelco modular housing — whether bullet, dome, turret, or PTZ mount. A facility managing 40+ cameras across multiple building wings can standardize on a single housing design and swap sensor heads as upgrade cycles or damage events occur. This reduces inventory fragmentation and cuts the per-site deployment cost when compared to buying matched camera/housing pairs.
H.265 compression is mature on the ARTPEC-9 generation and widely supported by modern NVR platforms. On a 16-camera deployment running 24/7 at 3MP/30fps, switching from H.264 to H.265 typically frees 30-45% of storage capacity — roughly $1,500-$2,500 in HDD costs for a 90-day rolling retention buffer. Paired with PoE Class 3's sub-13W draw, the IDL302-FXI fits comfortably into densely wired facilities without secondary power routing.
Low-light performance at 0.1 lux is sufficient for illuminated parking areas, lobby vestibules, and retail interiors; perimeter deployments beyond 50 feet in darkness will benefit from supplementary IR illumination or external floods. The F2.5 aperture gathers light aggressively, but sensor-level noise will rise in sub-0.05 lux scenes. Know your ambient light floor before committing to a pure low-light surveillance model without backlighting.
Integration with Pelco's ecosystem is seamless: ONVIF Profile T metadata flows directly to VMS event rules, microSD failover recording persists locally if the network link drops, and HTTPS encryption protects stream and credential payloads in transit. The modular housing system supports day/night mechanisms, motorized filter wheels, and varifocal motor mounts — this head slots into any of those configurations without redesign.
Marty AllisonPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
We've deployed the Pelco IDL302-FXI across retail chains, corporate campuses, and light-industrial sites where modular housing strategies reduce total cost of ownership and simplify field maintenance. The real value isn't the sensor itself—3MP at 30fps is commodity spec—but the swappability. On a 60-camera retail rollout using modular housings, we can standardize five housing types (bullet outdoor, dome recessed, turret wall-mount, etc.) and keep only one or two spare sensor heads in the service van. When a head fails or a customer wants an upgrade to 5MP down the line, we swap the imager, keep the housing, and save $300-$600 per site in re-installation labor and conduit work. That compounds across a thousand-unit install base. The PoE Class 3 footprint also matters: integrators often wire retail locations with budget-tier 48-port 802.3af switches; the sub-13W draw means you're not forced into pricier PoE+ infrastructure, and you avoid the capacity planning headache of mixed power consumption across a string of cameras.
Technical Highlights:
- Modular FXI Interface: Sensor head threads into any Pelco Sarix modular housing without external optics redesign. Enables field-swap upgrades and reduces spare parts inventory by 40-50% on multi-camera systems. Most competitors lock imager and housing together, forcing you to buy and install complete units on upgrade cycles.
- H.265 with Multi-Codec Fallback: H.265 saves 40-60% storage versus H.264 on equivalent quality; if your NVR doesn't support H.265 yet (older Milestone or Genetec), the head seamlessly falls back to H.264 stream. No firmware patches or middleware shenanigans required.
- 0.1 lux + WDR Day/Night: The combination of IR sensitivity and forensic WDR lets you run 24/7 without external lighting in lit parking areas and retail corridors. We've tested it in grocery-store perimeters and saw readable facial detail from 12-15 feet in complete darkness with IR on and WDR active. Beyond 20 feet or in unlit zones, you'll need supplementary floods.
- PoE Class 3 at Typical <13W: Standard 802.3af; won't trigger secondary power branches on budget switches. On a 48-port 802.3af switch with 40 cameras, you clear ~40W headroom—enough to add a future dome or varifocal without recabling.
- IP66, -40°C to +60°C Envelope: Sealed against dust and spray; thermally stable across outdoor arctic to desert duty cycles. We've run these in unheated loading docks (Maine winters, -20°C ambient) and Arizona rooftop mounts (140°F in full sun) without sensor drift or condensation failures.
- ONVIF Profile T Metadata: Line crossing, motion masks, and intrusion zones are pushed to the VMS as standardized event payloads—no proprietary Pelco plugin licensing required. Pairs cleanly with Milestone SMARTsearch and Genetec Rules Engine for low-noise alerting.
Deployment Considerations:
- Modular housings are Pelco-proprietary; this head will not thread into third-party bullet or dome mounts. Confirm housing availability and lead time before committing architecture to FXI—some older Pelco SKUs have been sunset, and housing availability can be regional.
- Low-light performance is excellent at 0.1 lux, but that's with IR assist active. In unlit outdoor scenes (perimeter beyond 50 feet, no ambient lighting), you'll need external IR or floodlights to achieve readable video. Don't spec this as a pure darkness camera without supplementary illumination.
- PoE Class 3 (~13W typical) leaves minimal headroom on 802.3af injectors if you're running multiple heaters or motorized lens elements in the same housing. If the housing spec includes motorized vari-focal or IR filter wheel, power draw may exceed 13W—verify actual housing+head consumption before final deployment.
- microSD failover recording is a nice-to-have but requires integration planning: your VMS or edge appliance must be configured to retrieve and replay SD card footage on NVR recovery. Test this workflow in pre-production if local recording is a compliance requirement.
- FXI heads are commonly bundled with housings; verify that the SKU you're ordering is the bare imager head, not a complete camera unit. Some Pelco distributors mix part numbers, and a full camera will cost 50-70% more than the head alone.
The IDL302-FXI is purpose-built for integrators and facility teams running standardized modular surveillance fleets. If you're managing 30+ cameras across multiple buildings and want to decouple sensor refresh from housing maintenance, this head pays for the housing-system upfront investment within two or three upgrade cycles. For one-off retail closets or small office deployments, a fixed-form 3MP bullet will be cheaper. For large-scale operations, the modularity wins. See the full Pelco catalog for compatible housings and complete modular system configurations.
