Part Number:
VP4551V
Model Number:
MNR3EGW1-24PBB8-6PS15D0A10-S-A
Power Configuration:
60A, 208V DELTA, 17.2kW
Physical Configuration:
70in / 1778mm, Vertical
Receptacle Type 1:
Locking IEC C13
Receptacle Quantity 1:
12
Receptacle Type 2:
Locking IEC C19
Receptacle Quantity 2:
12
Power Cord Plug Type:
3P+E (IP67)
Power Cord Length:
10ft / 3m
Chassis Color:
Black Powder Coat
Monitoring:
Input and Outlet power, Circuit/Breaker current, Environmental
Daisy Chain:
Yes, up to 50 devices
Display:
Local high visibility LED
Voltage:
200-240V Delta
Load Capacity:
17.2kW (208V)
Over Current Protection:
6 x 20A Double Pole Magnetic Breakers
Breaker AIC Rating:
10kAIC
Power Cable Wire Gauge:
6/4
Power Entry Location:
Bottom Front
Total Receptacle Quantity:
24
Receptacle Voltage:
208V
Network Connection:
Dual 10/100/1000Mbps Ethernet
Protocols Supported:
DHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, SNMP, Syslog, TACACS+
Data Access Formats:
CSV, JSON API, JSON datalog
Serial Connection:
RS232 via RJ45
Remote Sensor Jacks:
1 (Supports up to 16 Sensors)
Maximum Operating Temperature:
60C / 140F
Mounting:
Vertical
Toolless Mounting Spacing:
61.25in and 64.75in / 1556mm and 1645mm
Country of Origin:
USA, TAA Compliant, Buy American Act
Product Warranty:
5-year limited (registered) / 3-year (default)
Certification Agency 1:
FCC Part 15 Class A
Certification Agency 2:
RoHS Compliant
Certification Agency 3:
UL & c-UL Listed 62368-1
Chassis Dimensions:
70in x 2.25in x 2.6in / 1778mm x 58mm x 66mm
Doghouse Dimension:
1.4in / 36mm
Shipped Weight:
30lbs (13.61kg)
Input Voltage:
208V DELTA
Input Current:
60A x 3 Phase
Input Frequency:
50/60Hz
Power Measurement Accuracy:
1%
