Panduit PWBTB18CPG Wire Basket Trapeze Bracket With Center Hole Pre-galvanized

Overview

The Panduit PWBTB18CPG is an 18-inch trapeze bracket designed for mounting wire basket cable management systems from overhead. Its pre-galvanized steel construction offers durability and corrosion resistance, making it suitable for industrial and commercial environments where structured cabling requires secure overhead support. The center hole facilitates direct attachment to threaded rods or other mounting hardware, simplifying installation in complex overhead pathways. This bracket is engineered to provide a stable, load-bearing point for wire basket, ensuring the integrity of your cable runs.

Compatibility

This trapeze bracket is designed to work with Panduit's 18-inch wide wire basket products. It is compatible with various Panduit wire basket series, including but not limited to the WBS, WBM, and WBT series, provided the width matches. It also supports attachment to standard threaded rods (typically 3/8" or 1/2") for overhead suspension, common in data center and industrial facility installations.

Installation Notes

Installation requires appropriate overhead mounting hardware such as threaded rods and securing nuts (not included). Ensure the mounting surface and hardware can support the combined weight of the wire basket, cables, and bracket. Torque specifications for securing the bracket to the wire basket and the threaded rod should follow Panduit's general wire basket installation guidelines to prevent over-tightening or under-tightening, which could compromise structural integrity. The pre-galvanized finish should not be compromised during installation to maintain corrosion resistance.
