Paige Electric 236650707 Combo Wiegand Access Control Cable
Overview
The Paige Electric model 236650707 is a combo Wiegand access control cable engineered for integration with standard access control systems and credential readers. This cable handles data transmission between access control panels and door readers in commercial security installations—the backbone connection that keeps your reader-to-panel communication reliable and predictable. Wiegand protocol remains the industry standard for basic reader-to-panel signaling in office buildings, facilities, warehouses, and secured entry points, so a purpose-built cable rated for that protocol eliminates compatibility guesswork.
Key Features
- Wiegand Protocol Compatibility: Designed specifically for systems using Wiegand data format. This matters because Wiegand is low-voltage, low-speed signaling—roughly 5–10 kHz pulse frequency. A cable rated for Wiegand ensures clean pulse edges and minimal noise injection, which translates to fewer read errors at the panel.
- Combo Cable Construction: Combines power, data, and ground conductors in a single jacket. Reduces installation labor—one pull through conduit instead of three separate runs—and lowers the chance of mismatched or reversed connections.
- Commercial-Grade Shielding: Protects against electromagnetic interference (EMI) in electrically noisy environments—fluorescent lighting circuits, motor-driven door strikes, and VFD-controlled HVAC systems all generate RF noise. Proper shielding keeps false reads to a minimum.
- Standard Door Reader Integration: Works with legacy and contemporary Wiegand readers—HID iClass, Salto, Honeywell, and equivalent 26-bit or 37-bit card formats. No vendor lock-in at the cable level.
- Suitable for Office and Facility Deployments: Designed for interior and light industrial environments. Not rated for outdoor or washdown duty; if you need cable that survives direct hose spray or salt air, specify an industrial-grade access cable instead.
Integration and Deployment
The 236650707 integrates directly into any panel-to-reader infrastructure that accepts standard Wiegand terminations. Typical installation involves running the cable from the access control panel's reader port (usually a 26-pin or modular connector) to the credential reader at the door. Verify your panel's reader port voltage and current capacity before purchasing—most modern panels source 12VDC @ 500 mA minimum for reader power, and Wiegand data lines run at the same voltage logic level. If your reader or panel uses proprietary connectors or requires custom terminations, consult the reader manufacturer's wiring schematic or your panel integrator before ordering.
From a procurement standpoint, cable length is a critical variable not captured in the MPN alone. Confirm your required run length with your installer or systems integrator—longer runs (over 100 feet) increase capacitive loading on Wiegand pulse signals and can introduce timing skew. If you're spanning multiple floors or a large building footprint, consider breaking the run at an intermediate panel or using a Wiegand signal booster (available from most major control panel vendors).
Frequently Asked Questions
Q: Is the Paige Electric 236650707 rated for outdoor installation?
A: No. The 236650707 is designed for interior and facility environments. If you need to run cable outdoors or in wet locations, specify an industrial-grade, UV-resistant, jacketed access control cable with appropriate environmental ratings (IP67 or higher).
Q: Will the 236650707 work with my existing HID reader?
A: Yes, provided your HID reader outputs standard 26-bit or 37-bit Wiegand format and your access control panel accepts Wiegand input. Verify connector types (modular RJ-series vs. discrete pins) with your panel documentation before purchase.
Q: What's the maximum run length for this cable?
A: Wiegand signaling is low-speed (5–10 kHz) and typically supports reliable runs up to 100–150 feet. Beyond that, capacitive loading can degrade pulse timing. For longer distances, consult your panel manufacturer about signal conditioning or use an intermediate repeater.
Q: Does the 236650707 require special termination or crimping?
A: Termination depends on your panel and reader connector types. If both ends accept modular (RJ-series) connectors, standard RJ-45 or custom Wiegand plugs may be used. For pin-header or discrete screw-terminal connections, soldered or crimp connections are typical. Verify connector compatibility with your system integrator before purchase.
Q: Can I use the 236650707 with older legacy readers from the 1990s–2000s?
A: Most legacy readers that predate modern IP-based systems support Wiegand protocol, so yes—but verify your reader's pinout and voltage requirements. Older systems sometimes used non-standard voltage levels or proprietary signaling. Consult the reader's product documentation or your integrator.
Jerry TildsenPerspective based on aggregated IP Security Depot and affiliated engineering team experience.
The Paige Electric 236650707 is a straightforward but critical component: a purpose-built Wiegand cable for reader-to-panel integration. Access control installers tend to underestimate cable quality until they're troubleshooting intermittent read failures at 3 a.m., only to discover that a bargain-bin generic cable or undersized conductors introduced enough noise to degrade pulse fidelity. The 236650707 eliminates that risk by design.
Technical Highlights:
- Wiegand Protocol Optimization: Combo construction with shielded data conductors and proper impedance matching ensures clean 5–10 kHz pulse edges. This matters when your reader is 80–100 feet from the panel; signal degradation compounds over long runs, and poor shielding lets EMI corrupt the pulse train.
- Integrated Power and Data: Single-jacket combo cable reduces installation labor by eliminating separate power and data runs. One conduit pull instead of three also reduces potential for miswiring—a real problem on large retrofit projects with dozens of doors.
- Commercial-Grade Shielding: Effective against fluorescent ballast noise, motor-driven strikes, and variable-frequency drive interference—the three biggest culprits in noisy electrical environments like warehouses and facilities.
Deployment Considerations:
- Verify your panel's reader port connector type before purchase—modular RJ-series or discrete pin-header—so you can plan termination correctly. Mismatched connectors delay installation by days.
- If your run exceeds 100–150 feet, consult your panel manufacturer about signal conditioning or repeaters. Wiegand is low-speed, low-power signaling; capacitive loading over very long runs will cause timing skew and occasional read failures. Plan for this in large buildings or multi-floor deployments.
- Environmental limits: interior/facility use only. If you're installing readers outdoors or in washdown areas, this cable isn't the right choice—specify industrial-grade outdoor cable instead.
Deploy the 236650707 in any standard commercial access control infrastructure—office buildings, multi-tenant facilities, warehouses, and secured entry points using Wiegand-protocol readers and conventional panels. It's not glamorous, but it's the kind of unsexy, reliable infrastructure decision that keeps your system reading cards cleanly 24/7/365.
