Panduit R100X225V8C Turn-Tell Rotatable Cable and Wire Identification Labels

Overview

The Panduit R100X225V8C is a Turn-Tell™ vinyl label cassette engineered for permanent, readable wire and cable identification on 8 AWG through 4 AWG conductors — and on structured cabling up to Cat. 6A/10 Gig. If you've dealt with crowded cable trays where flat wrap-around labels fold under themselves and become unreadable, Turn-Tell's rotating tab design solves that problem by keeping the printed ID visible regardless of how the cable bundles. Each cassette ships with 75 labels, and the yellow print zone gives technicians and inspectors a high-contrast background that pops in low-light electrical panels, telecom rooms, and data center cable management lanes.

These labels are part of Panduit's identification and labeling line, designed to work with compatible Panduit portable label printers. If you're building out a structured cabling plant with cable labeling and identification as part of your close-out documentation package, the R100X225V8C targets the larger-gauge end of the spectrum where standard small-conductor labels don't fit cleanly.

Key Features

• Turn-Tell™ Rotating Tab Design: The tab swivels so the printed ID stays face-up even when cables are bundled tightly. On a 24-port patch panel with 24 cables leaving in parallel, this is the difference between a readable plant and a labeling exercise that only works on day one.
• Wire/Cable Range — 8 to 4 AWG: Sized specifically for larger conductors including power distribution wiring. This isn't a general-purpose label stretched to fit; the inner diameter and tab geometry are matched to this gauge range, so the label stays put without adhesive migration or slipping.
• Cat. 6 / Cat. 6A / 10 Gig Compatibility: The outer cable diameter of Cat. 6A cables (typically 7–9mm for shielded variants) falls within the fit range, making these usable on your structured cabling runs alongside power conductors — useful in mixed-use cable trays where you want a single label stock to cover both.
• Yellow Print Zone: High-visibility yellow background on the printed field aids readability in dim conditions — electrical rooms, below-floor cable runs, and densely populated panels where color coding by circuit or function is part of your labeling standard.
• Vinyl Construction: Vinyl resists abrasion and light chemical exposure better than paper, making it the right material for environments where cables are handled repeatedly during moves, adds, and changes. Labels don't degrade from incidental contact with cable dressing lubricants.
• 75 Labels per Cassette: A single R100X225V8C cassette covers a meaningful portion of a mid-size project — enough to label both ends of a 37-conductor run, or to complete a full panel. At a per-cassette pack quantity, ordering is straightforward for project-specific provisioning.
• RoHS Compliant: Meets RoHS requirements, relevant for installations subject to environmental materials compliance documentation — increasingly standard on government, healthcare, and EU-market projects.
• Carton Quantity of 10 Cassettes: If your project or ongoing maintenance operations consume labels regularly, the 10-cassette carton quantity means you can stock at volume without per-cassette overhead. Each cassette is individually packaged (package quantity of 1) for job-site distribution.

Integration and Compatibility

The R100X225V8C is a cassette-format label designed for use with Panduit's compatible portable label printer platforms. Before ordering, confirm your printer model accepts this cassette format — not all Panduit printers accept the full Turn-Tell cassette line. Consult your printer's compatible media list or reach out for pre-sales guidance on cable management and labeling solutions.

For structured cabling close-out documentation, these labels pair with network infrastructure patching and cable plant components where TIA-606 identification standards call for permanent, durable labeling on horizontal and backbone runs. The Cat. 6A callout on the label spec aligns with 10 Gigabit Ethernet deployments that require traceable identification per standards compliance.

What's in the Box

• 1x Panduit R100X225V8C Turn-Tell label cassette (75 labels, yellow print zone)

Frequently Asked Questions

Q: What wire gauge range does the R100X225V8C label fit?

A: The R100X225V8C is sized for 8 AWG through 4 AWG wire and cable, including Cat. 6 and Cat. 6A/10 Gig structured cabling runs.

Q: How many labels come in one cassette?

A: Each R100X225V8C cassette contains 75 individual Turn-Tell labels. The carton quantity is 10 cassettes if you need to stock at volume.

Q: Is the R100X225V8C RoHS compliant?

A: Yes. The R100X225V8C meets RoHS compliance requirements, which is relevant for installations requiring environmental materials documentation.

Q: What material are these labels made from?

A: The labels are constructed from vinyl, which provides abrasion resistance and durability in environments where cables are handled frequently during moves, adds, and changes.

Q: What printer is required to use the R100X225V8C cassette?

A: The R100X225V8C is a Panduit Turn-Tell cassette designed for compatible Panduit portable label printers. Verify cassette compatibility with your specific printer model before ordering — not all Panduit printers accept this cassette format.

Q: Why yellow — can I get this label in other colors?

A: The R100X225V8C is specifically the yellow print zone variant. Panduit's Turn-Tell line includes multiple color options for color-coded labeling standards. If a different color zone is required for your labeling scheme, look for other SKUs in the Turn-Tell family.

Marty Allison

The R100X225V8C is one of those products where the spec that matters most is the one people overlook: 75 labels per cassette at 8–4 AWG fit range. That combination tells you exactly what job this label was built for — power distribution and large-conductor structured cabling close-outs where you need quantity, durability, and a label that doesn't slide off a 4 AWG conductor the first time someone pulls the cable taut.

Technical Highlights:

• Turn-Tell Rotating Tab: Unlike wrap-around or flag labels that read in one plane, the rotating tab design keeps the ID readable regardless of cable orientation or bundle density — critical in populated electrical panels where you never get a straight-on sightline to every conductor.
• Vinyl Construction on 8–4 AWG: Vinyl holds up to repeated handling and incidental chemical contact. On larger-gauge conductors — especially in power distribution panels subject to maintenance cycles — a paper label lasts months; vinyl lasts the life of the installation.
• 75-Label Cassette / 10-Cassette Carton: At 75 per cassette and 10 cassettes per carton, a full carton covers 750 individual termination points. For a medium commercial electrical project with dual-end labeling, that's approximately 375 circuits — meaningful stocking quantity without over-ordering.

Deployment Considerations:

• Verify your Panduit portable printer model explicitly lists Turn-Tell cassette compatibility before committing to this label stock — cassette format compatibility is not universal across the Panduit printer line.
• The yellow print zone is fixed on this SKU. If your site labeling standard calls for color-by-circuit-type (e.g., red for emergency power, blue for normal power), you'll need additional Turn-Tell SKUs with matching color zones rather than using R100X225V8C as a universal solution.

This label is the right specification for structured cabling or power distribution close-out on projects where TIA-606 or similar identification standards require permanent, technician-readable labeling on Cat. 6A backbone runs and large-gauge power conductors in the same cable tray — a scenario common in commercial new construction and data center buildouts where mixed-use pathways are the norm.
