Panduit F91BNANNNSNM003 OS2 1F 3m SC APC to Unterminated Cord

Overview

The Panduit F91BNANNNSNM003 is a 3-meter (9.84 ft) OS2 single-mode fiber optic patch cord. It features a simplex SC connector with an APC (Angled Physical Contact) polish on one end, and an unterminated (raw) fiber on the other. This configuration is ideal for splicing applications within telecommunications rooms, data centers, or network distribution areas where a precise termination point is required. The yellow, Riser (OFNR) rated cable ensures compliance for in-building installations.

Compatibility

This patch cord is designed for use with Panduit Opti-Core® fiber optic systems and other equipment requiring OS2 single-mode fiber termination. The SC APC connector is compatible with standard SC receptacles, and the unterminated end is intended for fusion splicing or direct termination within patch panels or equipment where a specific connector type will be applied post-installation. It meets ISO/IEC 11801, TIA/EIA-568-C.3, TIA-604-3, and TIA-604-10 standards.

Installation Notes

The SC APC connector requires careful handling to maintain its angled polish, which minimizes back reflection. The unterminated end requires specialized tools and expertise for proper fusion splicing or termination. The OFNR rating indicates it is suitable for general-purpose use within buildings but not for use in vertical risers between floors unless specifically permitted by local codes. The cable diameter is 9mm.
