Panduit FW2ERLNSNSNM036 OM5 2F 1.6MM PC Ofnr LC Dup/sc DUP Stea

Panduit FW2ERLNSNSNM036 OM5 2F 1.6MM PC OFNR LC DUP/SC DUP STEA

Overview

The Panduit FW2ERLNSNSNM036 is a 36-meter (118.1 ft) OM5 Wideband Multimode fiber optic patch cable designed for rapid deployment in high-density data centers, telecommunications rooms, and equipment distribution areas. It features LC Duplex connectors on one end and SC Duplex connectors on the other, terminating 2 fibers within a 1.6mm jacket rated for Riser (OFNR) applications. This cable supports pre-terminated infrastructure, significantly reducing installation time and complexity for network backbone connections.

Compatibility

This cable is designed to connect equipment with LC Duplex fiber ports to equipment with SC Duplex fiber ports. It is compliant with TIA-568.3-D, ISO/IEC 11801, and ANSI/TIA-942-B standards, ensuring interoperability with a wide range of network devices, switches, servers, and patch panels that utilize these connector types and OM5 fiber specifications. It is suitable for use in any environment requiring high-bandwidth, short-reach optical connectivity.

Installation Notes

The OFNR (Riser) rating indicates this cable is suitable for vertical runs within building risers but not for use in plenums unless specifically permitted by local codes. The 1.6mm jacket provides a balance of protection and flexibility. Ensure proper bend radius is maintained during installation to prevent signal degradation; OM5 fiber requires a minimum bend radius of 1.0 inch (25.4mm) for a 2-fiber cable.
