Panduit OM4 2F 1.6MM PC Lszh LC Dup/sc PK1MOQ10 - FZ2ELLNSNSNM7.5

Panduit FZ2ELLNSNSNM7.5 OM4 2-Fiber LSZH LC/SC Duplex Fiber Patch Cable

Overview

The Panduit QuickNet™ FZ2ELLNSNSNM7.5 is a pre-terminated OM4 multimode fiber patch cable designed for high-density structured cabling in data centers, telecommunications rooms, entrance facilities, and equipment distribution areas. The 2-fiber, 1.6mm round cable ships ready to install — no field termination required — cutting deployment time in environments where labor cost and schedule pressure matter. The LC Duplex to SC connector pairing makes it the right choice when cross-connecting LC-equipped active equipment (switches, transceivers, media converters) to SC-terminated panels or older infrastructure.

OM4 multimode glass (50/125µm) supports 10GbE to 400m, 40GbE to 150m, and 100GbE to 100m over laser-optimized fiber — meaningful when selecting a cable for high-speed backbone runs rather than short patch connections. The Low Smoke Zero Halogen (LSZH) jacket is a hard requirement in enclosed or plenum-adjacent spaces where halogen off-gassing during a fire event is a life-safety concern — not just a checkbox. If your facility or local code requires LSZH, the FZ2ELLNSNSNM7.5 satisfies that requirement. If it doesn't, a standard PVC jacket cable at lower cost may be appropriate instead.

Compatibility

Works with any LC Duplex SFP+ or SFP28 transceiver port (common on Cisco, Arista, Juniper, HPE, and Ubiquiti switching platforms) connecting to SC-terminated fiber panels, SC-equipped media converters, or SC-port optical network units. The QuickNet™ sub-brand indicates factory-terminated and tested construction compatible with Panduit QuickNet modular cassette systems and standard EIA/TIA patch panels accepting SC simplex or duplex adapters. Conforms to TIA-568.3-D, ISO/IEC 11801, and ANSI/TIA-942-B — the three standards most commonly called out in data center design specifications and third-party audits.

Installation Notes

MOQ10 designation indicates this SKU is sold in a pack of 10 — confirm quantity before ordering if you need fewer. The 1.6mm jacket diameter suits high-density trays and cable managers with tight bend radius restrictions; minimum bend radius must be observed per TIA-568.3-D to avoid attenuation. LSZH jacketing is less flexible than PVC at low temperatures — account for this if routing in cold-aisle environments near mechanical supply air.
