Panduit OM3 12F LSZH PANMPO-LC UNIBOOT - FXTRL8NUSSNM030

Panduit FXTRL8NUSSNM030 Concise Descriptor

Overview

The Panduit FXTRL8NUSSNM030 is a 12-fiber, OM3 multimode fiber optic cable assembly designed for high-density network infrastructure. It features MPO connectors on one end and LC connectors on the other, utilizing a Uniboot design to reduce cable bulk and simplify management in data center racks and enterprise backbone applications. The LSZH (Low Smoke Zero Halogen) jacket ensures compliance with stringent fire safety regulations in sensitive environments.

Compatibility

This cable is engineered for use with standard MPO/MTP and LC fiber optic equipment. It is compatible with high-density patch panels, transceivers (SFP, SFP+, QSFP+), and switches requiring OM3 multimode fiber connectivity. Specific compatibility extends to Panduit's MPO/LC trunking systems and other manufacturers' equipment adhering to TIA/EIA-568 standards for OM3 fiber.

Installation Notes

The Uniboot design allows for polarity switching (A-to-A or A-to-B) without re-terminating the connector, simplifying field configuration. The cable's bend radius should be respected during installation to maintain signal integrity; a minimum bend radius of 25mm is recommended for OM3 fiber. Ensure connectors are clean before mating to prevent signal loss or damage.

What's in the Box

• 1x Panduit FXTRL8NUSSNM030 OM3 12F LSZH PANMPO-LC UNIBOOT Cable
