Panduit FRXTP77Y001F027 12-Fiber OM3 Plenum Fiber Trunk
The Panduit FRXTP77Y001F027 is a 12-fiber OM3 multimode pre-terminated fiber trunk engineered for rapid deployment in mission-critical datacenter and telecommunications environments. This 27-foot plenum-rated assembly eliminates field termination, delivering factory-tested reliability and significant labor savings on tight installation schedules. Compliant with TIA-568.3-D and ANSI/TIA-942-B datacenter standards, this trunk integrates seamlessly into Panduit's Opti-Core structured cabling architecture for scalable 10Gb Ethernet and enterprise network backbones.
Key Features
- 12-fiber OM3 50/125µm multimode trunk for high-density datacenter interconnects
- Pre-terminated and factory-tested — eliminates field splicing and reduces installation time by 70%
- Plenum-rated OFNP jacket complies with NEC Article 770 for air-handling spaces
- Supports 10GBASE-SR up to 300 meters and 40/100GBASE-SR4 up to 100 meters
- TIA-568.3-D and ISO/IEC 11801 compliant for standards-based infrastructure
- Opti-Core platform integration with color-coded polarity management
OM3 laser-optimized 50/125µm multimode fiber delivers 10 Gigabit Ethernet performance over distances up to 300 meters at 850nm, making this trunk ideal for datacenter backbone runs, equipment distribution area (EDA) interconnects, and high-speed server-to-switch links. The 12-fiber configuration provides six duplex channels, supporting structured migration from 1Gb to 10Gb speeds without re-cabling. Pre-terminated assemblies eliminate the variability and insertion loss penalties associated with field termination, ensuring consistent <0.3dB insertion loss per connector and <0.5dB total channel loss per TIA-568.3-D guidelines. Factory testing includes end-face inspection, insertion loss verification, and polarity validation — documentation ships with each trunk.
Plenum-rated OFNP jacketing meets NEC 770.113(B) requirements for installation in environmental air spaces, drop ceilings, and raised-floor plenums without additional conduit. The 27-foot length is optimized for typical intra-floor backbone runs, entrance facility cross-connects, and vertical riser transitions between telecommunications rooms. Pre-terminated trunks reduce installation labor by 70% compared to field-spliced alternatives — a critical advantage in time-sensitive datacenter builds, tenant fit-outs, and equipment refreshes where downtime windows are measured in hours. Opti-Core color-coded boots and polarity labeling simplify MAC (moves, adds, changes) workflows and reduce troubleshooting time when tracing circuits across high-density fiber panels.
Compliance with TIA-568.3-D, ISO/IEC 11801, and ANSI/TIA-942-B ensures this trunk integrates into Tier III and Tier IV datacenter designs, federal GSA specifications, and enterprise campus networks requiring auditable structured cabling standards. Panduit Opti-Core components (panels, cassettes, enclosures, trunks) share common polarity schemes and mechanical interfaces, enabling consistent end-to-end fiber architectures from backbone to horizontal distribution. This trunk is the field-proven choice for commercial integrators deploying scalable 10Gb infrastructures where factory quality, code compliance, and rapid deployment determine project success.
