Middle Atlantic OFR 45 Degree Flat Elbow - OFR12

Middle Atlantic OFR12 45 Degree Flat Elbow

Overview

The Middle Atlantic OFR12 is a 45-degree flat elbow fitting designed for use with Middle Atlantic's Middle Atlantic OFR open-frame raceway system. It solves the specific routing problem of changing cable direction horizontally in a flat plane — useful when conduit runs need to turn corners along walls, above ceilings, or across the floor of a cable management pathway without introducing a sharp 90-degree bend that stresses conductors. Where a standard elbow would force an abrupt direction change, the 45-degree geometry distributes the bend across a gentler arc, reducing strain on network, power, and low-voltage cabling routed through open-frame raceways.

Compatibility

The OFR12 is engineered to integrate with Middle Atlantic's OFR (Open Frame Raceway) product family. It connects directly to OFR straight sections and other OFR fittings — including couplers, tees, and inside/outside elbows — to build a continuous, reconfigurable pathway. Confirm the raceway channel width of your installed OFR run matches the OFR12 fitting profile before ordering; Middle Atlantic offers OFR components in multiple widths, and fittings are not cross-compatible between channel sizes. For rack and enclosure accessory builds requiring vertical transitions rather than flat turns, pair with the appropriate OFR inside or outside elbow fitting instead.
