Middle Atlantic Nivo 9/16 Flush Charcoal Gray - AUNV220DG2CHG

Middle Atlantic AUNV220DG2CHG Nivo Flush Acoustic Ceiling Tile, Charcoal Gray

Overview

The Middle Atlantic AUNV220DG2CHG is a 2' x 2' flush-profile acoustic ceiling tile from the Middle Atlantic Nivo line, designed for AV and security equipment rooms where ceiling aesthetics matter as much as acoustic performance. Built from 100% PET Felt polyester, it drops directly into a standard 9/16" layin grid — the type found in most commercial suspended ceilings — and sits flush with the grid face for a clean, finished look that holds up in conference rooms, control rooms, and network equipment spaces. If you're fitting out a room that will house surveillance equipment, AV infrastructure, or access control panels and you need the ceiling to look professional rather than like a utility closet, this tile addresses exactly that problem.

The AUNV220DG2CHG targets integrators and facilities teams who are finishing a space alongside their network video recorder and structured cabling work and need ceiling tiles that integrate cleanly into the broader room design without ordering custom fabrication.

Key Features

• 2' x 2' Format (60.33 x 60.33 cm): Matches the most common commercial drop-ceiling grid module. You can pull an existing standard tile and drop this in without modifying the grid or cutting the tile — reducing install time on day-of-commissioning when every hour counts.
• 9/16" Layin Mounting Method: Designed for the narrow 9/16" exposed-tee grid that dominates modern commercial construction. The tile rests on the grid flanges — no clips, no adhesives, no tools required for placement. Easy to lift for above-ceiling cable runs after the fact.
• Flush Profile: The face of the tile sits at the same plane as the grid face rather than recessing or projecting. In a finished conference room or executive AV suite, flush tiles read as intentional interior design rather than a utility ceiling. The 2" total height of the tile body (5.1 cm) fits standard grid depth without interference.
• PET Felt (100% Polyester) Construction: PET felt is a textile acoustic material that absorbs mid and high-frequency sound — useful in rooms with hard walls and equipment fan noise, where echo degrades voice clarity during video calls or remote monitoring sessions. Polyester construction also means the tile does not contain glass fibers, so handling during install and subsequent above-ceiling access won't leave irritants on surfaces or skin.
• Charcoal Gray Finish: A neutral dark tone that reads well under both cool and warm lighting in AV and security control environments. Charcoal conceals surface dust and minor soiling far better than white or off-white tiles — a practical consideration in equipment-dense rooms with higher air circulation and particulate.
• Zero Depth Clearance Requirement: The specification lists 0" depth below the grid, meaning the tile face is fully contained within the grid plane. No below-grid projection to obstruct wall-mounted displays, speaker lines of sight, or camera coverage angles near the ceiling plane.

Integration & Compatibility

The AUNV220DG2CHG is designed specifically for 9/16" exposed-tee layin grid systems, which represent the majority of commercial drop-ceiling installations in North America. It is not a direct replacement for 15/16" wide-face grid systems — verify your grid flange width before ordering. The 2' x 2' module is compatible with both 2'x2' and 2'x4' grid layouts (used as a half-module in 2x4 runs). This tile integrates naturally into AV equipment rooms alongside rack and enclosure systems and structured cable management infrastructure. For rooms requiring acoustic treatment in conjunction with camera or intercom placement, the flush profile ensures no mechanical conflict with surface-mount devices at the ceiling plane. Coordinate with your grid manufacturer on maximum tile weight if loading additional acoustic material above.

Frequently Asked Questions

Q: What ceiling grid type does the AUNV220DG2CHG fit?

A: The AUNV220DG2CHG is designed for 9/16" layin (exposed-tee) grid systems, which are the most common commercial suspended ceiling grid type in North America. It is not rated for 15/16" wide-face grids — measure your grid flange before ordering.

Q: Does the AUNV220DG2CHG require any tools or hardware to install?

A: No. The layin mounting method means the tile rests on the grid flanges by gravity — no clips, fasteners, or adhesives are needed. It can be lifted out and replaced without tools, which is useful for above-ceiling cable access after installation.

Q: What are the exact dimensions of the AUNV220DG2CHG?

A: The tile covers a 2' x 2' (60.33 x 60.33 cm) grid opening. The body height is 2 inches (5.1 cm). The flush profile means zero depth projection below the grid face.

Q: Is the PET Felt material safe for use in occupied commercial spaces?

A: PET Felt is 100% polyester — it contains no glass fibers. This makes it safer to handle during installation and during subsequent above-ceiling access compared to fiberglass-based ceiling tiles, with no airborne glass fiber risk in occupied rooms below.

Q: Can this tile be used in a 2' x 4' ceiling grid?

A: Yes. A 2'x2' tile can be used to fill half of a 2'x4' grid opening. You would need two tiles per 2x4 module. Confirm the grid cross-tee is present at the 2' midpoint of each 4' run.

Q: Is the charcoal gray color consistent across production runs?

A: As with most textile-based ceiling products, minor dye-lot variation can occur between manufacturing batches. For large installations requiring color consistency across many tiles, order the full quantity from a single purchase to minimize visible variation.

Marty Allison

The AUNV220DG2CHG is the tile I spec when a client wants the equipment room to look like it belongs in the building rather than in a server closet. The 9/16" layin fit means no grid modification — you drop it in, and the flush profile holds the face plane consistent with every other tile in the ceiling. That matters when the room doubles as a client-facing demo space or a C-suite conference room running video surveillance and AV on the same infrastructure.

Technical Highlights:

• Flush Profile, 2" Body Height: At 5.1 cm total height, the tile body fits standard commercial grid depth without below-grid projection — no interference with wall-mounted displays, camera sight lines, or ceiling-mounted speakers in security and AV control rooms.
• PET Felt (100% Polyester): No glass fiber content means above-ceiling access for cable pulls after install doesn't contaminate the room below. In occupied security operations centers, that's a meaningful safety distinction versus traditional fiberglass tiles.
• Charcoal Gray Colorway: Conceals particulate accumulation in high-airflow equipment rooms far better than white tiles — reduces visible soiling between maintenance cycles, which matters in 24/7 monitoring environments where aesthetics affect perceived professionalism.

Deployment Considerations:

• Verify the existing grid is 9/16" exposed-tee before ordering — a 15/16" wide-face grid is visually similar but will not seat this tile correctly. Measure the visible flange width, not just the opening.
• The 2' x 2' format requires a 2' cross-tee at every module boundary. In older 2'x4' grid runs without mid-span cross-tees, you'll need to add tees before installing the AUNV220DG2CHG — factor that into your rough-in schedule.

This tile is the right call for security operations centers, AV equipment rooms, and command-and-control spaces where the ceiling treatment needs to hold up aesthetically through daily above-ceiling access while delivering functional acoustic absorption in hard-surfaced rooms with fan-heavy rack equipment.
