ACTi NLSPROMP Newline Signage PRO Media Player
Overview
The NLSPROMP is a 4K interactive display system designed for surveillance control rooms, command centers, and collaborative spaces requiring dual-mode operation—live camera feeds and dynamic signage on a single wall-mounted or stand-deployed screen. Available in five sizes (55", 65", 75", 86", 98"), each NLSPROMP delivers 3840×2160 native resolution with a 178° wide viewing angle, making it suitable for multi-operator environments where clarity and simultaneous visibility matter. Running Android 13 with native Google EDLA certification, the player integrates seamlessly with Google Classroom, Google Drive, and enterprise surveillance VMS platforms supporting ONVIF or direct RTSP streaming.
Compatibility
The NLSPROMP works with any IP camera or surveillance system that outputs standard video streams (H.265, H.264, or MJPEG compression). USB Type-C input supports laptop pass-through without separate power—the built-in 65W USB-C power delivery charges connected devices while displaying content. Wi-Fi 6 module supports up to 30 simultaneous client devices, enabling multi-user collaboration in control-room and training scenarios. Optional ACTi camera modules integrate directly into the display frame for embedded capture without separate camera hardware. Android 13 OS and user profile customization support multi-operator role-based access without requiring a separate control workstation.
Installation Notes
Wall mounting and mobile stand mounting are both supported across all five size variants. Operating temperature range is −20°C to +60°C with 0–90% RH tolerance, allowing deployment in climate-controlled command centers and outdoor-adjacent sheltered spaces. Memory footprint is 8 GB RAM across all models, sufficient for simultaneous multi-stream playback and touch-responsive interface operation. Embedded 20W speakers eliminate the need for external audio amplification in medium-to-large control rooms (55–75 inch) but may require supplemental sound in 86–98 inch installations with high ambient noise.
What's in the Box
- 1× NLSPROMP display unit (55", 65", 75", 86", or 98" variant selected)
- 1× Wall mounting bracket or mobile stand hardware (per mount option selected)
- 1× USB Type-C power/charging cable
