Hanwha WRT-P-5204L 24TB WAVE Network Video Recorder

Hanwha WRT-P-5204L 24TB WAVE Network Video Recorder

The Hanwha WRT-P-5204L-24TB is a compact mini-tower network video recorder purpose-built for mid-to-large distributed camera deployments. This turnkey system combines enterprise-grade Wisenet WAVE VMS software with robust Intel-based hardware, delivering 470 Mbps sustained recording bandwidth and support for up to 64 channels across single-site or geographically dispersed installations. Pre-configured with 24TB raw storage capacity and professional-grade licensing, it eliminates software procurement delays and reduces time-to-deployment in data centers, security operations centers, and edge recording environments.

Key Features

• High-Capacity Storage: 24TB raw storage across 3.5" SATA HDDs, expandable to 36TB with three drive bays; 470 Mbps sustained recording bandwidth supports 64-channel Wisenet WAVE deployments
• Wisenet WAVE VMS Pre-Installed: Enterprise video management software with four Professional licenses included, eliminating separate licensing procurement and accelerating go-live
• 14th Gen Intel Core i5 Processor: Current-generation x86 architecture with 16GB DDR4 RAM and 256GB M.2 SSD, enabling responsive live-view playback, multi-channel search, and real-time analytics processing
• Dual Gigabit Network: One on-board GbE NIC plus one PCIe-based GbE port for network redundancy, camera source separation, or dedicated management traffic isolation
• Multiple Connectivity Options: 2× DisplayPort video outputs, comprehensive USB 3.2 and USB 2.0 rear/front ports, 3.5mm audio input/output, supporting extended peripheral integration
• Enterprise-Class Power: 500W 80 Plus Platinum power supply with wide 100–240V AC input range ensures energy efficiency and global deployment flexibility
• Ubuntu Linux 22.04 LTS OS: Stable, long-term support operating system foundation with proven security and reliability for continuous recording operations

Technical Specifications

• Form Factor: Mini-tower (372.9mm × 173mm × 420mm; 24 lbs)
• Storage: 24TB installed capacity, 36TB maximum; 256GB M.2 SSD OS drive
• Recording Performance: 470 Mbps sustained bandwidth; 64-channel capacity
• Memory & Processor: 16GB DDR4 RAM; 14th Gen Intel Core i5
• Video Outputs: 2× DisplayPort with included DisplayPort-to-HDMI adapter
• Network: Dual Gigabit Ethernet (1× on-board, 1× PCIe)
• USB: 2× USB 3.2 Gen 2, 2× USB 3.2 Gen 2 Type-C, 2× USB 2.0 (rear); 2× USB 3.2 Gen 1, 1× USB 3.2 Gen 2 Type-C, 1× USB 3.2 Gen 2x2 Type-C (front)
• Audio: 3.5mm input (front), 3.5mm output (rear)
• Certifications: UL, cUL, CB, FCC

Applications

Ideal for multi-camera surveillance in corporate data centers, security operations centers (SOCs), retail chains, transportation hubs, and industrial facilities requiring local high-capacity recording with redundant networking. The modular storage design and dual network interfaces support both centralized and edge-based recording architectures.

Ted Perry

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

The WRT-P-5204L-24TB represents a pragmatic solution for organizations deploying Wisenet WAVE across distributed sites. The 14th Gen Intel Core i5 with 16GB DDR4 provides sufficient compute headroom for live playback and analytics without over-specification; the dual GbE ports enable network resilience without requiring external switches for camera/management separation. The 24TB configuration balances capacity against deployment footprint—sufficient for 7–14 days of 64-channel 1080p recording depending on codec and frame rate—while the three-bay architecture future-proofs for capacity expansion.

Ubuntu 22.04 LTS ensures long-term vendor support through 2032, reducing lifecycle risk. Pre-loaded Wisenet WAVE with four Professional licenses eliminates licensing friction common in large deployments. The 500W Platinum-rated PSU reflects enterprise-grade power discipline, important for 24/7 operation in temperature-controlled environments.

This system is best suited for organizations with existing Hanwha/Wisenet ecosystems seeking plug-and-play deployment over custom-built solutions.
