Hanwha WRT-P-3104MW1-2TB Micro NVR 2TB

Hanwha WRT-P-3104MW1-2TB Micro NVR 2TB

The Hanwha WRT-P-3104MW1-2TB is a compact, purpose-built Network Video Recorder designed for small to mid-sized IP surveillance installations where space constraints and rapid deployment are critical. This micro form factor NVR supports up to 16 camera channels and arrives pre-configured with Wisenet WAVE VMS and 4 Professional licenses, enabling immediate operational deployment with minimal setup overhead.

Key Features

• Micro Form Factor Design: Measures 1.42" W × 7.01" D × 7.17" H and weighs 3.09 lbs, making it ideal for retail, office, hospitality, and education environments where installation discretion matters. Optional VESA mount supports behind-monitor placement for maximum space efficiency.
• Dual M.2 SSD Architecture: Dedicated solid-state drives isolate video storage (up to 2TB capacity) from operating system functions (256GB Windows 11 IoT Enterprise LTSC 2024), eliminating performance contention and ensuring fast boot times and responsive VMS operations.
• 14th Generation Intel Core i3 Processor with 8GB RAM: Provides sufficient compute resources for real-time H.265 transcoding, simultaneous multi-stream playback, and stable VMS performance across all 16 concurrent camera feeds without degradation.
• 45 Mbps Recording Bandwidth: Accommodates mid-resolution and H.265-compressed video streams across all channels, maximizing storage efficiency while preserving forensic video quality.
• Wisenet WAVE VMS Pre-Installed: Industry-standard video management software arrives fully configured with 4 Professional licenses, eliminating software procurement and licensing delays.
• 3.5mm Universal Audio Support: Front-panel audio input enables synchronized audio recording from connected sources, supporting investigative playback and incident verification.
• 90W External Power Adapter: Efficient DC power design minimizes heat generation and simplifies installation in compact environments.
• International Certifications: UL, cUL, CB, and FCC listings ensure compliance with North American and international safety and electromagnetic standards.

Technical Specifications

• Recording Channels: 16
• Storage: 2TB capacity with microSD support
• Operating Temperature: 50°F to 95°F (10°C to 35°C)
• Power: DC via 90W external adapter
• Mount Type: Optional VESA mount

Ideal Applications

The WRT-P-3104MW1-2TB is purpose-built for retail storefronts, small office buildings, healthcare facilities, educational institutions, and hospitality venues requiring professional surveillance with minimal physical footprint. Its pre-loaded VMS and compact design reduce deployment complexity while maintaining enterprise-grade video management capabilities.

Ted Perry

Perspective based on aggregated IP Security Depot and affiliated engineering team experience.

This micro NVR bridges the gap between consumer-grade DVRs and full-scale enterprise systems. The segregated SSD architecture is particularly valuable—by isolating OS storage from video storage, Hanwha eliminates a common performance bottleneck where OS disk I/O competes with continuous video writes. The 14th-gen Intel Core i3 is appropriately specced for 16-channel H.265 workloads; H.265 compression roughly halves bitrate compared to H.264, making the 45 Mbps aggregate bandwidth realistic for mid-to-high resolution deployments.

Pre-installed Wisenet WAVE VMS with 4 Professional licenses removes significant friction from small deployment sales cycles. Organizations avoid separate software licensing negotiations and can begin recording within hours rather than days. The optional VESA mount is a smart design choice for space-constrained environments—behind-monitor mounting keeps the NVR invisible to visitors while remaining accessible for maintenance.

Temperature operating range of 50°F–95°F suits climate-controlled indoor environments typical of retail and office spaces, though outdoor or industrial applications would require external environmental enclosures. UL/cUL/CB/FCC certifications satisfy North American building codes and insurance requirements.
